Below is a table listing of possible RAID migration schemes:
To
From RAID 0
RAID
1
RAID X
5

NAS Stacking

The Thecus IP storage's capacity can be expanded even further using the stackable
function. With it, users can expand the capacity of their network storage systems
up to 5 other stack target volumes which are located in different systems. These
can be stacked through single network access like SMB or AFP acting as a share
folder type.
From the main menu, the stackable feature is located under "Storage". Please refer
the figure below for reference.
A. Add a Stack Target Volume
From the figure above, click Add to access the stackable target device
configuration page. Please refer to the figure below:
With the added stack target you can "Enable" or "Disable" the stack target now or
later depending on usage required.
RAID 5
[RAID 1] HDDx2 to [RAID 5] HDDx3
[RAID 1] HDDx2 to [RAID 5] HDDx4
[RAID 1] HDDx3 to [RAID 5] HDDx4
[RAID 5] HDDx3 to [RAID 5] HDDx4 [RAID 5] HDDx3 to [RAID 6] HDDx4
58
RAID 6
[RAID 1] HDDx2 to [RAID 6] HDDx4
[RAID 1] HDDx3 to [RAID 6] HDDx4
