6.4 Load Control

The UPS indicates the Output Load level by LCD display (as described in the chapter 4).
When the Output load is higher than nominal value the UPS warns of Overload condition by LCD display, by
emitting a continuous acoustic alarm.
The UPS warns of an Overload less than 110% by acoustic alarm.
An Overload between 110% and 130% is accepted for about 30 seconds and after UPS switches automatically off.
The UPS switches immediately off if the Overload is higher than than 130%.
Once the requested power is back within range, the UPS switches automatically to the Normal mode.
Make sure that the UPS never indicates Overload condition.
Do not connect a load greater than rated value to the UPS (see POWER specifications in
the chapter "Technical Characteristics"), as this may damage the unit. In this case the
warranty is void.

6.5 Fault Condition

The UPS indicates the Fault condition by LCD display, by emitting a continuous acoustic alarm.
During Fault condition, the UPS doesn't supply Output power and so all the supplied devices are switched off.
7

Communication Interfaces

The UPS is factory-equipped with RS232 and USB Communication Interfaces. On the UPS rear side there are the
connectors of the Interfaces.
Only one of the RS232/USB communications can be activated at one time. To activate RS232 communication it is
sufficient to connect the RS232 cable only; to activate USB communication it is sufficient to connect the USB cable
only.
The RS232 and USB signals are all isolated through photo-couplers from the dangerous voltages that are
present inside the UPS.
Connecting to the Web site www.tecnoware.com, it is possible to download, free of charge, the update UPS
management Software, compatible with the most popular Operative Systems
.
UPS EXA 1.1-1.5-2.2-2.6-3.2 Rack Mount 9
