Specifications

• Protocols - Point-To-Point Protocol (PPP), Multilink Point-To-Point Protocol (MLPPP), and
Serial Line Internet Protocol (SLIP)
• EtherNet Lan Interface - 10Base-T (twisted pair) or 10Base-2 (ThinNet) BNC connector
• WAN Interface - 3 asynchronous Links (RJ11) jacks
• Command Port - 19.2K bps Asynchronous
• One 1meg by 36 byte at 70 nanosecond SIMM is 4mb DRAM
Caution: SIMM speed and size cannot be mixed

EtherNet Port

• One Ethernet Interface - 10Base-T (twisted pair) RJ45 connector or 10Base-2 ThinNet BNC
connector

Command Port

• Single 19.2K bps asynchronous Command Port using a short RJ45 to DB25 cable with a
DB25 female connector

WAN Links

• Three internal K56flex
to 168K bps.

Electrical/Physical

• Voltage - 115 VAC (Standard), 240 Volts AC (Optional)
• Frequency - 47 to 63 Hz
• Power Consumption - 10 Watts
• Dimensions - 1.625" high x 6" wide x 9" deep
5.63cm high x 22.34cm wide x 33.51cm deep
• Weight - 2 pounds (.92 kg)

Requirement

• PC with Windows 3.1x, and one serial comm port to connect to the Command Port of the
ProxyServer
* Though this modem is capable of 56K bps download performance, line impairments, public
telephone infrastructure and other external technological factors currently prevent maximum 56K
bps connections.
MTPSR3-200
TM
modems* with MultiLink Point-To-Point Protocol for a bandwidth up
