Chapter 1: Setting Up and Using the Presenter 1280 Monitor
6
3. Connect the power cable to the Presenter 1280 monitor and then to an
electrical outlet, as shown in Figure 1-4. (Figure 1-4 shows the power
cable for the U.S.A. The power cable for your country may look
different.)
Connect the socket end to the power connector on the base of the
Presenter 1280 monitor.
Connect the other end to a three-pronged grounded electrical wall
outlet or power strip.
Check that each end is seated firmly.
Once the system recognizes Presenter 1280, the LED on its base turns green.
Now go to "Turning On the Presenter 1280 Monitor" on page 7.
Note: The power supplies for Silicon Graphics low-end workstations and
for Presenter 1280 are auto-ranging. With the appropriate power cable or
adapter for your country, you can plug the monitor into almost any power
source (50-60 Hz, 110/220 VAC).
To workstation
Connecting the Power Cable
Figure 1-4
