Chapter 1: Setting Up and Using the Presenter 1280 Monitor

Connecting the External Cables

If the Presenter 1280 board is not already installed in your workstation,

install it now, referring to the installation manual that comes with it.

To use Presenter 1280, you must connect two cables—the interface cable and

the power cable. The connectors have an elongated D shape. Make sure the

D shapes match each other. If the cable is not installed correctly, the image

on Presenter 1280 will be distorted.

You do not need to turn off the workstation before connecting the

Note:

cables. If you are using Presenter 1280 and either the power cable or the

interface cable become disconnected, simply reconnect the cable and the

software restarts Presenter 1280.

Follow these steps to connect the cables.
