Chapter 1: Setting Up and Using the Presenter 1280 Monitor

Adjusting the Brightness

Figure 1-15 Monitor Panel

Switching to 24-Bit Mode

18
3. Rotate the base up and slide Presenter 1280 out from under the two
projector clips.
Presenter 1280 is now ready to be used as a desktop monitor.
You can control the brightness on Presenter 1280 with the Monitor Panel.
Follow these steps to adjust the brightness of the display:
1. Open the Monitor Panel in either of the following ways:
From the Find menu in the Toolchest, choose "Control Panels," and
double-click the monpanel icon.
From a UNIX shell, enter:
monpanel
The Monitor Panel shown in Figure 1-15 appears.
2. To adjust the brightness of the display, move the slider.
The default color mode on Presenter 1280 is 18-bit. In this mode, some
smooth shaded images appear banded. If you wish to decrease this banding,
and if you have 24-bit graphics, you can switch to 24-bit mode. In that mode,
however, some colors may flicker. So you may want to switch back and forth,
depending on the types of images you are viewing.
When you choose 24-bit mode, the display creates additional colors by
averaging the true colors it displays in 18-bit mode. The result is a palette of
15,990,784 colors, not quite the 16,777,216 in true 24-bit).
To switch between 18-bit and 24-bit mode, use the Monitor Panel. Follow
these steps:
