Speakers
Sleep button
Speaker connector
(to overhead projector)
Figure 1-2 Rear View of Presenter 1280
• Rear stereo speakers.
• Sleep button—to enable and disable the display.
• Speaker connector—to connect the speaker cable to the Dukane 28A682
overhead projector.
• Interface connector—to connect the interface cable to the workstation.
• Power connector—to connect the power cable.
®
• Kensington lock connector—to secure Presenter 1280 with a
Kensington locking device.
You are now ready to connect the external cables.
Setting Up the Presenter 1280 Monitor
Kensington lock connector
Power connector
Interface connector (to workstation)
