Chapter 1: Setting Up and Using the Presenter 1280 Monitor
2
Caution: The display is made of glass, coated with optical films and is the
most expensive component in the monitor. A sharp instrument such as a pen
can scratch the surface. Striking the surface with a hard object can break the
glass.
3. Tilt the base of Presenter 1280 to form a stand, as shown in Figure 1-1.
4. Place it on a flat surface.
You can leave your regular CRT monitor connected to the
Note:
workstation and turned on while using Presenter 1280.
You may want to take a moment to familiarize yourself with the following
Presenter 1280 features, as shown in Figure 1-1 (front view), and Figure 1-2
(rear view).
LED
Figure 1-1 Front View of Presenter 1280
• LED—to show the status. When the Presenter 1280 monitor is on and
enabled, the LED is solid green.
• Camera slot—to attach a camera.
• Front stereo speakers.
Slot for Camera
Speakers
