Setting Up the Presenter 1280 Monitor

Chapter 1
1. Setting Up and Using the Presenter 1280
Monitor
To use the Presenter 1280 monitor with your workstation, the Presenter 1280
adapter board must already be installed. If it is not, install it first, following
the instructions that came with the board.
This chapter explains how to set up Presenter 1280 as a monitor for your
workstation, and how to use it on the customized Dukane 28A682 overhead
projector to project images on a screen. It also includes information on using
the Presenter 1280 software.
Caution: The Presenter 1280 monitor is designed to function at maximum
performance and reliability with the customized Dukane 28A682 Overhead
Projector. If you use another projector, cooling of the display, stable
mounting, and brightness of the projected image will all be compromised. A
bright overhead projector without proper cooling of the display may cause
permanent damage to the Presenter 1280 monitor.
To set up Presenter 1280 with the workstation, follow these steps.
1. Unpack the Presenter 1280 monitor.
Lift Presenter 1280 and the external cables from the box. It's a good
idea to save the original shipping materials in the event that you
need to return it for service.
Remove Presenter 1280 from the plastic bag.
2. Remove the protective film from the screen, being careful not to get
fingerprints on the coated glass surface.
