1.12.2 Memory/Expansion Connectors

The AP440FX motherboard has four 72-pin SIMM sockets for main memory. These sockets
accept standard SIMM 72-pin modules, as long as they satisfy the requirements described in the
"Main System Memory" section of this specification, starting on page 12.
The AP440FX motherboard uses a PCI/ISA riser connector (J6J2) to provide for expansion PCI or
ISA boards. The associated riser board can support either two or three PCI slots. A pair of
jumpers on the AP440FX motherboard must be set to define the number of PCI slots on the riser
board. Refer to Figure 8 on page 35 for jumper block details. Table 7 shows the pinout listing for
the PCI/ISA riser connector.
Table 7.

PCI/ISA Riser Connector (J6J2)

Pin Signal Name
A1 IOCHK#
A2 SD7
A3 SD6
A4 SD5
A5 SD4
A6 SD3
A7 SD2
A8 SD1
A9 SD0
A10 IOCHRDY
A11 AEN
A12 SA19
A13 SA18
A14 SA17
A15 SA16
A16 SA15
A17 SA14
A18 SA13
Pin Signal Name
B1 GND
B2 RSTDRV
B3 Vcc
B4 IRQ9
B5 -5 V
B6 DRQ2
B7 -12 V
B8 0WS#
B9 +12 V
B10 GND
B11 SMEMW#
B12 SMEMR#
B13 IOW#
B14 IOR#
B15 DACK3#
B16 DRQ3
B17 DACK1#
B18 DRQ1
Motherboard Description
Pin Signal
E1 GND
E2 GND
E3 PCIINT1#
E4 PCIIINT2#
E5 Vcc
E6 Key
E7 Vcc
E8 PCIRST#
E9 GNT0#
E10 REQ0#
E11 GND
E12 PCKLE
E13 GND
E14 AD30
E15 3.3 V
E16 Key
E17 3.3 V
E18 AD28
Pin Signal Name
F1 GND
F2 GND
F3 PCIINT3#
F4 PCIINT4#
F5 Vcc
F6 Key
F7 Vcc
F8 PCKLF
F9 GND
F10 GNT1#
F11 GND
F12 REQ1#
F13 AD31
F14 AD29
F15 3.3 V
F16 Key
F17 3.3 V
F18 AD27
continued
