1.12.8.5 Parallel Port
Table 22 lists the pinout and signal names for the parallel port connector.
Table 22. Parallel Port Connector Pinout
Pin Signal Name
1 STB#
2 PPD0
3 PPD1
4 PPD2
5 PPD3
6 PPD4
7 PPD5
8 PPD6
9 PPD7
10 ACK#
11 BUSY
12 PE
13 SLCT
34
Description Pin
Strobe 14
Data Bit 0 15
Data Bit 1 16
Data Bit 2 17
Data Bit 3 18
Data Bit 4 19
Data Bit 5 20
Data Bit 6 21
Data Bit 7 22
Acknowledge 23
Port Busy 24
Paper end 25
Select
Signal Name Description
AFD# Auto Feed
ERROR# Fault
INIT# Initializing printer
SLCTIN# Select input
GND Chassis Ground
GND Chassis Ground
GND Chassis Ground
GND Chassis Ground
GND Chassis Ground
GND Chassis Ground
GND Chassis Ground
GND Chassis Ground
