Rainbow 1 IP Phone User Manual

2. Keypad of IP Phone

Menu
VoiceMail
Mute
Headset
Hold
Redial
2.1 Describe of the buttons and Screen
Soft Keys
Function of
Softkey
Status Indicator
LED
LCD Screen
Navigation keys
OK key
Cancel key
ATCOM TECHNOLOGY CO., LIMITED
Line key
Press to select a function which displayed at the softkey zone
of screen
Display all optional functions at the last line of LCD screen.
Indicates the phone's status,
If the phone is being started ,the LED is on
If the phone is standby, the LED is off
If there is income calling, the LED will be twinkling. The
frequency is 120ms on, 120ms off.
All information such as date, time, phone number, incoming
caller's ID(if available),line/call status, extension numbers
and the soft key features are displayed on it.
Allows users to navigate (left, right, up, down).
Confirm users' operation.
Cancel users' operation.
LCD Status Indicator LED
Volume Speaker
www.atcom.cn
Navigation
OK
Cancel
Soft Key
Programmable
Key
Dial pad
