R3(S) IP Phone User Manual
2、Keypad of IP Phone
Menu
Voice Mail
Mute
Headset
Hold
Redial

2.1Describe of the buttons and Screen

Soft Keys
Status Indicator
LCD Screen
Line Key
ATCOM TECHNOLOGY CO., LIMITED
Line key
Press to select a function which displayed at the softkey
zone of screen
Display all optional functions at the last line of LCD screen
Indicates the phone's status.
All information such as date, time, phone number,
incoming caller's ID(if available),line/call status, extension
numbers and the soft key features are displayed on it.
Show extension status and choose corresponding line.
Long hold the line key will enter the editor interface.
14
www.atcom.cn
LCD Status
Navigation
OK
Cancel
Soft Key
Memory Key
Dial pad
