Serial port configuration

This.page.provides.all.access.to.settings.concerned.with.the.two.serial.ports.
(modem.and.power.control).that.are.situated.at.the.rear.of.the.AdderView.
CATxIP.1000.unit..
To get here
1. Using.VNC.viewer.or.a.browser,.log.on.as.the.'admin'.user.
2. Click.the.'Configure'.button.in.the.top.right.corner.
3. Click.the.'Serial.Port.Configuration'.option.
Options Port Use
This.option.determines.whether.the.RS232.serial.OPTIONS.port.at.the.rear.of.the.
unit.will.be.used.for.connection.to.power.control.switches.or.to.synchronise.the.
operation.of.two.AdderView.CATxIP.1000.units..
Baud Rate
This.option.determines.the.speed.of.the.RS232.serial.OPTIONS.port..The.other.
communication.settings.are.fixed.as:.No.parity,.8.bit.word,.1.stop.bit.
