Computer system (via CAM)

Each.computer.system.is.connected.to.the.
AdderView.CATxIP.1000.unit.via.a.Computer.
Access.Module.(CAM).and.standard.category.5,.
5e.or.6.cabling..CAMs.are.available.in.various.
formats.to.suit.differing.computer.system.types.
and.their.particular.connector.styles.
Each.CAM.uses.Adder.Keep.Alive.technology.
to.ensure.that.the.keyboard.and.mouse.inputs.
to.the.computer.remain.active,.even.when.
the.particular.channel.is.not.selected..This.action.ensures.that.there.are.no.
connection.delays.or.problems.as.the.port.is.selected...
To connect a computer system
1. Ensure.that.power.is.disconnected.from.the.AdderView.CATxIP.1000.unit.
and.the.system.to.be.connected..
2. Locate.the.required.CAM.(there.are.five.types.available).and.attach.its.video,.
keyboard.and.mouse.(PS/2-style,.USB.or.Sun).to.the.relevant.sockets.on.the.
computer.system..
A range of different
connector combinations
are made available
across the five CAM
formats
3. Lay.a.suitable.length.of.category.5,.5e.or.6.cabling.between.the.computer.
system.and.the.AdderView.CATxIP.1000.unit..The.maximum.length.of.the.
cable.can.be.up.to.10.metres.(32.feet),.however,.bear.in.mind.that.the.
overall.distance.between.a.remote.user.and.any.computer.must.not.exceed.
300.metres.(980.feet).
LOCAL GLOBAL
USER USER
IP
POWER
IN
CAM
COMPUTER POWER
SYSTEM SWITCH
USB keyboard/mouse
Sun keyboard/mouse
PS/2-style mouse
PS/2-style keyboard
Audio
Video
4. Attach.the.connector.of.the.cable.
run.to.the.socket.of.the.CAM.
Green indicator - power present
Yellow indicator - signal activity
Category , e or
cable to AdderView
CATxIP 000
5. At.the.other.end.of.the.cable.run,.attach.the.cable.connector.to.one.of.the.
sockets.labelled.
COMPUTER CONNECTIONS
CATxIP.1000.unit.....
AdderView CATxIP
Category , e or
cable from CAM
Computer
Access
Module
Note: CAMs derive power from the
computer system via either the PS/2-style
keyboard connector, USB or SUN connector.
.on.the.rear.panel.of.the.AdderView.
Note: Each CAM is
specifically shaped so
that it can be secured
using a cable tie around
its middle. In this way,
000 rear panel
two CAMs can also be
neatly joined together,
back-to-back..
