- Page 1 AdderView Secure User.Guide INSERT CARD CHIP DOWNWARDS ...
-
Page 2: Table Of Contents
Contents Welcome Operation Introduction..................2 Tamper-evident.seals..............13 AdderView.Secure.-.features............3 Selecting.computers..............13 Standard.items................4 Error.indicator................13 Additional.items................4 Smart.card.reader...............13 Installation Further information Locations..................5 Troubleshooting.................14 Cabling.recommendations............5 Summary.of.threats.and.solutions..........14 Tamper-evident.seals..............5 Getting.assistance...............16 Links.overview................5 Warranty..................17 Mounting..................6 Safety.information..............17 Making.connections..............7 Radio.Frequency.Energy............18 Connections.to.computer.systems..........7 Connections.to.user.console.peripherals........9 Connection.to.power.supply..........12... -
Page 3: Introduction
Welcome Introduction The AdderView Secure range of products are highly robust KVMA switches for Various strategies are employed to ensure complete Common keyboard, mouse, video separation between the switched channels: monitor and speakers are able critical applications. When information absolutely must not be leaked between to access multiple high security •... -
Page 4: Adderview.secure.-.Features
AdderView Secure - features The AdderView Secure is housed in an electromagnetically shielded robust casing that measures just [w x d x h] 9.25” x 5.9” x 1.73” (235mm x 150mm x 44mm) - the height is 1U within a 19” rack. All channel switching is achieved solely using the front panel buttons which are clearly indicated, as are the rear panel connections. -
Page 5: Standard.items
Standard items Additional items AdderView Secure 5V, A Power supply plus country-specific mains cable Rack brackets Including four screws Installation CD-ROM... -
Page 6: Installation
Installation Locations Links overview Please consider the following important points when planning the location of The rear panel of the unit is well marked, however, the diagram below offers the AdderView Secure unit: additional clarity on how best to arrange your connections. •... -
Page 7: Mounting
Mounting The AdderView Secure unit offers two main mounting methods: • Supplied four self-adhesive rubber feet • Optional rack brackets 2 . 0... -
Page 8: Making.connections
Making connections Connections to the AdderView Secure unit do not need to follow the precise order given in this user guide, although if one or more systems must be hot- plugged, connect these after all other connections have been made. IMPORTANT: All rear panel connectors are clearly marked, however, take great care not to cross connect any links or devices. - Page 9 Connections to computer systems (continued) Connecting video inputs The unit provides full DVI/I connections for video. This means that it can receive, and transfer, any VGA or DVI input (from analog to single or dual link digital) up to the following maximum resolutions and rates: •...
-
Page 10: Connections.to.user.console.peripherals
Connections to user console peripherals To connect a keyboard and mouse To connect speakers Note: The AdderView Secure unit can directly accommodate only a USB-style 1 Wherever possible, ensure that power is disconnected from the unit and the keyboard and mouse. If required, you can use suitably shielded conversion host computer(s) to be connected. - Page 11 Connecting video inputs The unit provides full DVI/I connections for video. This means that it can receive, and transfer, any VGA or DVI input (from analog to single or dual link digital) up to the following maximum resolutions and rates: •...
- Page 12 DDC.pin.conditions. AdderView.Secure.unit.response recommended that the DDC lines are disconnected in the cable between the AdderView Secure and the monitor. Alternatively, Adder would be happy Connected DDC data is harvested from the connected video to discuss configuring the AdderView Secure with a DDC policy to suit your display during unit power on and written to all organisation.
-
Page 13: Connection.to.power.supply
Connection to power supply Important: Please read and adhere to the electrical safety information given within the Safety.information section of this guide. In particular, do not use an unearthed power socket or extension cable. To connect the power supply 1 Attach the output connector of the power supply (country specific power supplies are available) to the socket on the far right of the rear panel. -
Page 14: Operation
Operation Error indicator In operation, the AdderView Secure unit allows you to quickly and securely switch between up to four systems. Strictly only one system may be accessed at The red error indicator is located on the right side a time, whereupon the common keyboard and mouse are linked to that system. of the front panel and is labelled ERR. -
Page 15: Further Information
Mixed systems are possible in certain special microprocessor software and so is not compromised by any circumstances but these will require specialist assistance from Adder causing data to leak changes to the microprocessor technical support. - Page 16 Threat Solution Threat Solution Data being sent to ports Channel switching is controlled by the front Forced malfunctions due It is potentially possible to create forced by means of faulty or panel buttons only with all keyboard hotkey to overloaded signalling. malfunctions by constantly and quickly subverted keyboards or or mouse switching capabilities removed...
-
Page 17: Getting.assistance
If you are still experiencing problems after checking the list of solutions in the Troubleshooting section then we provide a number of other solutions: • Adder.Technology.website – www.adder.com Check the Support section of our website for the latest solutions and driver files. -
Page 18: Warranty
• No user serviceable parts within power adapter - do not dismantle. warranty period, Adder will replace or repair it free of charge. No liability can be • Plug the power adapter into a socket outlet close to the module that it is accepted for damage due to misuse or circumstances outside Adder’s control. -
Page 19: Radio.frequency.energy
Radio Frequency Energy All interface cables used with this equipment must be shielded in order to maintain compliance with radio frequency energy emission regulations and ensure a suitably high level of immunity to electromagnetic disturbances. FCC Compliance Statement (United States) European EMC directive 89/336/EEC This equipment generates, uses and can radiate radio frequency energy This equipment has been tested and found to comply with the limits for a class... - Page 20 © 2007 Adder Technology Limited All trademarks are acknowledged. Release 1.0a July 2007 Part No. ADD0071 Adder Technology Limited, Adder Corporation, Technology House, 29 Water Street, Trafalgar Way, Bar Hill, Newburyport, Cambridge, CB3 8SQ, MA 01950, United Kingdom United States of America...
