Local User - ADDER AdderView CATxIP 1000 User Manual

Local user

A.locally.connected.video.monitor,.keyboard.
(and.mouse).are.required.during.the.initial.
configuration..These.are.also.useful.during.
normal.use.to.allow.quick.local.control.of.any.
connected.computer.systems..The.AdderView.
CATxIP.1000.unit.directly.supports.USB.style.
keyboards.and.mice....
LOCAL GLOBAL
USER USER
IP
POWER
IN
CAM
COMPUTER POWER
SYSTEM SWITCH
To connect the local user port
1. Position.a.suitable.video.monitor,.keyboard.and.mouse.in.the.vicinity.of.the.
AdderView.CATxIP.1000.unit.such.that.their.cables.will.easily.reach.
2. Attach.the.video.monitor,.keyboard.and.mouse.connectors.to.the.sockets,.
collectively.labelled.as.
USER CONSOLE
1000.unit..
From video monitor
From USB keyboard and mouse
,.at.the.rear.of.the.AdderView.CATxIP.
AdderView CATxIP 000
