Setting IP access control

The.golden.rule.with.this.feature.is.'Include.before.you.exclude'.or.to.put.it.
another.way.'Arrange.allowed.addresses.in.the.list.before.the.denied.addresses'..
This.is.because.the.positions.of.entries.in.the.list.are.vitally.important..Once.a.
range.of.addresses.is.denied.access,.it.is.not.possible.to.make.exceptions.for.
particular.addresses.within.that.range..For.instance,.if.the.range.of.addresses.
from.A.to.F.are.denied.access.first,.then.the.address.C.could.not.be.granted.
access.lower.down.the.list..Address.C.needs.to.be.placed.in.the.list.before.the.
denied.range.
IMPORTANT: This feature should be configured with extreme caution as it is
possible to deny access to everyone. If such an error occurs, see
access control
for details about how to regain access.
In.the.list,.access.control.addresses.prefixed.by.'+'.are.allow.entries.while.those.
prefixed.by.'–.'.are.deny.entries.
To get here
1. Using.VNC.viewer.or.a.browser,.log.on.as.the.'admin'.user.
2. Click.the.'Configure'.button.in.the.top.right.corner.
3. Click.the.'Network.Configuration'.option.
To define a new IP access control entry
1. Click.the.Add.button.to.display.a.popup.dialog:
Network/Address
Clearing IP
Enter.the.network.address.
that.is.to.be.allowed.or.denied.
access..If.a.range.of.addresses.
is.being.specified.then.specify.
any.one.of.the.addresses.
within.the.range.and.use.the.
Mask.entry.to.indicate.the.size.
of.the.range.
2. Enter.the.base.network
access.setting.
3. Click.the.OK.button.
To reorder access control entries
IMPORTANT: When reordering, ensure that any specific allowed addresses are
listed higher in the list than any denied addresses. Take care not to invoke any
deny access settings that would exclude valid users.
1. In.the.access.control.list,.click.on.the.entry.to.be.moved.
2. Click.the.Up.or.Down.buttons.as.appropriate.
To edit/remove access control entries
1. In.the.access.control.list,.click.on.the.appropriate.entry.
2. Click.either.the.Edit.or.Remove.button.as.appropriate.
Access
Mask
Enter.an.IP.network.mask. Use.the.arrow.buttons.to.
that.indicates.the.range.of. select.either.'Allow'.or.
addresses.that.are.to.be. 'Deny'.as.appropriate.
allowed.or.denied.access..
For.instance,.if.only.a.single.
specified.IP.address.were.to.be.
required,.the.mask.entry.would.
be.255.255.255.255.in.order.
to.specify.a.single.location..See.
Calculating the mask for IP
access control.for.details.
address,.the.mask.and.select.the.appropriate.
