Parts List - DeVilbiss Compact MINI Technical Bulletin

Page 6 SB-2-858
REF.
DESCRIPTION
NO.
1 Air Cap Retaining Ring
2 Slip Ring
3 Air Cap
5 Retaining Ring Seal
6 Air Cap & Ring
8 Fluid Nozzle
9 Separator
12* Body Bushing Seal
13 Body Bushing
14 Body Bushing & Seal
15 Fluid Needle
16* Needle Spring
17* Needle Spring Pad
18 Fluid Adjusting Knob
Fluid Adjusting Knob,
19
Spring & Pad Kit
20* Retaining Clip
21 Spreader Valve Body
22* Spreader Valve Seal
Spreader Valve
23
Adjusting Knob
24* Valve Pin
25 Spreader Valve Assembly
26* Needle Packing
27* Packing Spring
28 Packing Nut
Packing, Spring &
29
Packing Nut Kit
30 Air Valve Body
31 Air Valve Cage

PARTS lIST

PART NO. QTY.
1
1
1
1
See chart 1, p13 1
See chart 2, p13 1
COMM-2-K5 1
1
1
SN-6-K 1
See chart 2, p13 1
1
1
1
PRO-3-K 1
1
1
2
1
1
COMM-401-K 1
1
1
1
SN-404-K 1
1
REF.
DESCRIPTION
NO.
32 Air Valve Poppet
33 Air Valve Spring
34 Air Valve Spring Pad
35 Air Valve Seal
36 Air Valve Assembly
Trigger Stud Screw
37*
(T20 TORX)
38 Trigger
39* Trigger Stud
40 Trigger, Stud & Screw Kit
41 Stud and Screw Kit
42 Air Inlet
44 Airflow Valve
45 Circlip
51 Gravity Cup Kit
52 Drip Check Lid (kit of 5)
56 Air Valve Service Tool
SERVICE PARTS
Spray Gun Repair Kit
(includes items marked *)
Seal & Pin Kit, kit of 5
(items 20, 22 and 24)
For accessories, see page 16
PART NO. QTY.
1
1
1
SN-34-K5 1
SN-402-K 1
1
1
1
SN-42-K 1
SN-405-K5 1
SN-40-K 1
PRO-404-K 1
1
SRI-510 1
GFC-2-K5 1
1
PRO-415-1
GTI-428-K5
