PARTS REPlACEMENT/MAINTENANCE
ChART 1 – AIR CAPS
PART NO. fOR
AIR CAP
COMM-100-HS1
COMM-100-TS1
COMM-100-RS1
NOTE: When removing air cap from retaining ring, don't remove the Slip Ring (2) or Retaining Ring Seal (5) from the
Retaining Ring . Damage to the parts may occur . Slip ring and Retaining Ring seal are not available as replacements .
Simply wipe parts clean and reassemble with new or clean air cap .
ChART 2 – fluID NOZZlE RANGE & fluID NEEDlE
PART NO. ON fluID NOZZlE
COMM-200-08
COMM-200-10
COMM-200-12
COMM-200-14
NOTE: When replacing the fluid nozzle or fluid needle, replace both at the same time . Torque to 70 in-lbs (8 Nm) .
Don't over tighten the fluid nozzle . Use 6mm Spanner supplied with the gun and check with a torque wrench .
MARKING ON
TEChNOlOGY
AIR CAP
HVLP
TRANS-TECH ®
TRANS-TECH ®
PART NO. NEEDlE
COMM-300-0810
COMM-300-1214
RECOMMENDED
INlET PRESSuRE
HS1 29 .0 psi (2 .0 bar)
TS1 29 .0 psi (2 .0 bar)
RS1 14 .0 psi (1 .0 bar)
SB-2-858 Page 13
AIR flOW
(l/min)
135
100
55
