Page 4 SB-2-858
1 Compact MINI Gravity Feed Spraygun
1 Compact MINI Gravity Feed Cup
1 Cup Filter
1 Funnel
1 Spanner (6mm hex and 10mm A/F)
Air Cap
1
(nickel plated brass for long durability)
Air Cap Retaining Ring
2
(allows easy rotation of air cap)
3 Fluid Nozzle
Fluid Needle
4
(grooved stem for easy removal)
Fluid Inlet (7/16" – 14 UNC thread) – accepts
5
DeVilbiss SRI cup systems
Air Inlet
6
(universal thread, accepts G 1/4 & 1/4 NPS)
Self Adjusting Needle Packing
7
(for trouble free operation)
8 Trigger (ergonomic for comfort)
Trigger Stud & Screw
9
(easy replacement design)
Gun Body
Air Cap
Fluid Nozzle, Fluid Needle, Fluid Inlet, Trigger Stud
Springs, Clips, Screws
Seals, Gaskets
Trigger
Air Inlet, Body Bushing, Spreader Valve Body, Air Valve Nut,
Air Cap Retaining Ring, Knobs
Air Valve Assembly
Air Supply Connection
Maximum Static Air Inlet Pressure
Nominal Gun Air Inlet Pressure for HVLP (HS1) and
Trans-Tech ® (TS1 & RS1) with gun triggered
Fluid Supply Connection
Service Temperature
Gun Weight (gun only)
(with cup)
KIT CONTENTS (All MODElS)

CONSTRuCTION fEATuRES

MATERIAlS Of CONSTRuCTION

SPECIfICATIONS & TEChNICAl DATA
1 Torx/Flat Blade Screwdriver
1 Small Cleaning Brush
1 Large Cleaning Brush
1 Service Bulletin
Fan Air Adjustment
10
(stepless regulation for fan to round spray)
Fluid Adjustment
11
(stepless regulation of fluid volume)
Anodized, forged aluminium gun body
12 (ergonomic, good looking & durable, easy
to clean)
13 125cc Acetal Cup (easy clean, anti-static)
14 Cup Lid with Drip Free Vent (avoid drips)
Air Valve (design offers low pull force & low
15
pressure drop)
Gun acceptable for waterborne and solvent
16
borne applications
Anodized aluminium
Nickel plated brass
Stainless steel
Stainless steel
Solvent resistant
Chrome plated steel
Chrome plated brass
Stainless steel, HPDE
Universal 1/4" BSP and 1/4" NPS male
P1 = 175 psi (12 bar)
29 psi (2 .0 bar)
7/16 – 14 UNC
32 to 104°F (0 to 40°C)
15 .0 oz (425 g)
17 .1 oz (485 g)
