2.6 Setting the Communication Timeout and Keepalive
Explanation
2-12
Keepalive
key to select Ethernet and then press the
1.
Press the
Basic=Ethernet
key to select K.Alive and then press the
2.
Press the
Ethernet=K. Alive
key to select On and then press the
3.
Press the
The setting complete screen appears.
Keep alive=On
Keep alive
Setting complete
5
Press the ESC key to return to the higher level menu. To save the settings and
exit from Basic Setting mode, proceed to "Saving the Settings."
Saving the Settings
Press the ESC key to return to the Basic= screen.
1.
key to select End and then press the
2.
Press the
key to select Store and then press the
3.
Press the
The settings are activated, and the Operation mode screen appears.
The communication timeout function and the keepalive function can be configured.
• Communication Timeout
• Selecting On or Off
If On is selected, set the timeout time.
• Timeout Time
If communication timeout is enabled, the connection is dropped if no data transfer
is detected over a time period specified here.
Selectable range: 1 to 120 minutes
• Enabling (On)/Disabling (Off) Keepalive
Select On to enable the keepalive function.
• Saving the Settings
To activate the settings made in the Basic Setting mode, the settings must be saved.
<Related Topics>
Keepalive: Section 1.1
* When the
key,
key, or
the operation is reversed as when the respective key is pressed by itself.
CHARACTER
key is pressed while holding down the SHIFT key,
key.
key.
key.
key.
key.
