Omega SBR-EW100 User Manual

Communication interface
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Recorder
SBR-EW100/EW180
Communication Interface
User's Manual
IMSBR08-E2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SBR-EW100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Omega SBR-EW100

Summary of Contents for Omega SBR-EW100

  • Page 1 Recorder SBR-EW100/EW180 Communication Interface User's Manual IMSBR08-E2...

  • Page 3: Foreword

    The following five manuals, including this one, are provided as manuals for the SBR-EW100/EW180 Recorder. Please read all of them. The figures used in this manual are mostly of the SBR-EW100. If you are using the SBR-EW180, refer to the figures for reference.
  • Page 4 • Other company and product names are trademarks or registered trademarks of their respective holders. Functional Enhancement of the SBR-EW100 Recorder Functions have been added or modified on the SBR-EW100 Recorder since system version 1.11. You can check the system version on the system display. For details, see the SBR-EW100 User's Manual (IMSBR07-E( ) ).

  • Page 5: How To Use This Manual

    How to Use This Manual Structure of the Manual This user’s manual consists of the following sections. Chapter 1 Overview of the Communication Functions Gives an overview of the communication functions. Chapter 2 Using the Ethernet Interface (/C7 Option) Explains the specifications of the Ethernet interface and how to use the interface. Chapter 3 Using the RS-422A/485 Communication Interface (/C3 Option) Explains the specifications of the RS-422A/485 communication interface and how to use the interface.
  • Page 6 How to Use This Manual Conventions Used in This Manual • Unit • k: Denotes 1000. Example: 5 kg, 100 kHz • K: Denotes 1024. Example: 640 KB • Note The following markings are used in this manual. Improper handling or use can lead to injury to the user or damage to the instrument. This symbol appears on the instrument to indicate that the user must refer to the user’s manual for special instructions.

  • Page 7: Names Of Parts And Basic Key Operations

    You use the panel keys and the display to configure the communication functions. For a description of other parts of the recorder, see section 3.1 in the Recorder User’s Manual. (The figure below is of the SBR-EW100 Recorder.) Front Rear Panel...
  • Page 8 Names of Parts and Basic Key Operations Basic Key Operations This section describes basic operations on the front panel keys to change various settings. • Execution Modes The recorder has the following execution modes. • Operation mode: A mode used to perform recording and monitoring. •...
  • Page 9 Names of Parts and Basic Key Operations • Entering Values key or SHIFT + key or SHIFT + Use the key to move the cursor. Use the key to change a digit value. You repeat these steps to enter the value. SHIFT key + A=000.000.000.000 Target digit...
  • Page 10 Names of Parts and Basic Key Operations • Exiting from Basic Setting Mode Press the ESC key several times to return to the Basic= screen. key or SHIFT + Press the key to select End and then press the key. The setup save screen appears.

  • Page 11: Table Of Contents

    Contents Foreword .................................... i Functional Enhancement of the SBR-EW100 Recorder ......................ii How to Use This Manual ..............................iii Names of Parts and Basic Key Operations ........................v Chapter 1 Overview of the Communication Functions Communication Functions Using the Ethernet Interface (/C7 Option) ..............1-1 Functional Construction .............................
  • Page 12 Contents Chapter 4 Commands Command Syntax ............................4-1 Response ................................. 4-2 A List of Commands ............................4-3 Execution Modes and User Levels ........................4-3 Setting Commands ............................4-3 Basic Setting Commands ..........................4-4 Control Commands ............................4-5 Output Commands ............................4-5 RS-422A/485 Dedicated Commands ........................
  • Page 13 Contents Appendix Appendix 1 ASCII Character Codes .......................... App-1 Appendix 2 Output Flow of FIFO Data ........................App-2 Appendix 3 Login Procedure ............................App-4 Appendix 4 A List of Error Messages .......................... App-6 Setting Errors ..............................App-6 Operation Errors ............................App-7 Communication Errors ..........................

  • Page 14: Chapter 1 Overview Of The Communication Functions

    Chapter 1 Overview of the Communication Functions Communication Functions Using the Ethernet Interface (/C7 Option) The recorder can be equipped with an optional Ethernet interface. For details on how to use the Ethernet interface, see chapter 2. Functional Construction The following figure shows the relationship between the communication function of the recorder and the Ethernet interface.

  • Page 15: Communication Functions Using The Ethernet Interface (/C7 Option)

    1.1 Communication Functions Using the Ethernet Interface (/C7 Option) Maintenance/Test Server • Outputs Ethernet communication information such as connection information and network statistics from the recorder. • The commands that can be used Maintenance/Test commands. <Related Topics> • Ethernet interface settings: Section 2.3 •...

  • Page 16: Other Functions

    1.1 Communication Functions Using the Ethernet Interface (/C7 Option) Other Functions • Login Function Only users that are registered in advance can access the Setting/Measurement and Maintenance/Test servers. • Users are identified by their user name and password. • You can register one administrator and six users. Administrator privileges The administrator can use all the functions on the Setting/Measurement and Maintenance/Test servers User Privileges...

  • Page 17: Communication Functions Using The Rs-422A/485 Communication Interface

    Communication Functions Using the RS-422A/485 Communication Interface (/C3 Option) The recorder can be equipped with an optional RS-422A/485 communication interface. For details on how to use the RS-422A/485 communication interface, see chapter 3. Functional Construction The following figure shows the relationship between the communication function of the recorder and the RS-422A/ 485 communication interface.

  • Page 18: Setting/Measurement Server

    Chapter 2 Using the Ethernet Interface (/C7 Option) Ethernet Interface Specifications Basic Specifications Item Specifications Electrical and mechanical specifications Conforms to IEEE 802.3 (Ethernet frames are of DIX specification) Transmission medium type 10BASE-T Protocol TCP, IP, UDP, ICMP, and ARP The Maximum Number of Simultaneous Connections and the Number of Simultaneous Use The following table shows the maximum number of simultaneous connections, the number of simultaneous users,...

  • Page 19: Connecting The Ethernet Interface

    Connecting the Ethernet Interface When Connecting Only the Recorder and a PC Connect the recorder and the PC via a HUB as in the following figure. SBR-EW100/EW180 Recorder 10BASE-T straight cable SBR-EW100/EW180 Recorder 10BASE-T straight cable When Connecting to a Preexisting Network The following figure illustrates an example in which a recorder and a PC are connected to the network.

  • Page 20: Configuring The Ethernet Interface

    Configuring the Ethernet Interface Set the host name and IP address of the recorder. You do not have to set the DNS (domain name system). Setup Items Ethernet Host Host Domain Host name Domain name Local IP IP address Subnet mask Default gateway DNS On/Off Server...
  • Page 21 2.3 Configuring the Ethernet Interface IP Address, Subnet Mask, and Default Gateway Press the key to select Ethernet and then press the key. Basic=Ethernet Press the key to select Local IP and then press the key. Ethernet=Local IP Set the IP address of the recorder and then press the key.
  • Page 22 2.3 Configuring the Ethernet Interface Set the primary domain suffix and then press the key. Key operations • Use the key to select the digit for entering a character. • Use the CHARACTER key to select the character type. • Use the key to select the character you wish to enter.
  • Page 23 2.3 Configuring the Ethernet Interface • G (Default Gateway) • Set the IP address of the gateway (router, etc.) used to communicate with other networks. The default value is 0.0.0.0. • Set this value according to the system or the network to which the recorder belongs. In some cases, this setting may not be necessary.

  • Page 24: Checking The Connection Status

    Checking the Connection Status The connection status of the Ethernet interface can be confirmed with the indicator that is located to the left of the Ethernet port on the recorder. Indicator Connection Status of the Ethernet Interface ON (Green) The Ethernet interface is electrically connected. Blinking (Green) Transmitting data.

  • Page 25: Registering Users

    Registering Users Users that can access the recorder via the Ethernet network must be registered. This function is called login function. Setup Items Ethernet Login Login Use/Not LoginSet Level Register User Admin/User On/Off User name Password Procedure For a description of the basic operations, see “Basic Key Operations” on page v. Entering Basic Setting Mode Hold down the key for 3 seconds to display the Setting mode screen.
  • Page 26 2.5 Registering Users Set the user name and then press the key. Key operations • Use the key to select the digit for entering a character. • Use the CHARACTER key to select the character type. • Use the key to select the character you wish to enter. User= Set the password and then press the key in the same fashion as in step 8.
  • Page 27 2.5 Registering Users Note • The relationship between the login function and the user name that is used when accessing the recorder is as follows: • When the login function is set to “Use” • The registered user name and password can be used to login to the recorder. •...
  • Page 28 Setting the Communication Timeout and Keepalive The communication timeout function and the keepalive function can be configured. Setup Items Ethernet Timeout Timeout Duration On/Off Timeout time K.Alive Keep alive On/Off Procedure For a description of the basic operations, see “Basic Key Operations” on page v. Entering Basic Setting Mode Hold down the key for 3 seconds to display the Setting mode screen.

  • Page 29: 2.6 Setting The Communication Timeout And Keepalive

    2.6 Setting the Communication Timeout and Keepalive Keepalive Press the key to select Ethernet and then press the key. Basic=Ethernet Press the key to select K.Alive and then press the key. Ethernet=K. Alive Press the key to select On and then press the key.

  • Page 30: Chapter 3 Using The Rs-422A/485 Communication Interface (/C3 Option)

    Chapter 3 Using the RS-422A/485 Communication Interface (/C3 Option) RS-422A/485 Communication Interface Specifications This section describes the RS-422A/485 communication interface specifications. Item Specifications Terminal block type Number of terminals: 6, terminal attachment screws: ISO M4/nominal length of 6 mm Electrical and mechanical Complies with the EIA-422A(RS-422A) and specifications EIA-485(RS-485) standards...

  • Page 31: Terminal Arrangement And Signal Names And The Connection Procedure Of The Rs-422A/485 Communication Interface

    Terminal Arrangement and Signal Names and the Connection Procedure of the RS-422A/485 Communication Interface Terminal Arrangement and Signal Names Rear panel ALARM CHART SDA SDB SG RS-422A REMOTE SD SD SG RS-422A SD SD SG RD RD FG RD RD FG RDA RDB FG Terminal Name Description...

  • Page 32: Connection Example With A Host Computer

    3.2 Terminal Arrangement and Signal Names and the Connection Procedure of the RS-422A/485 Communication WARNING To prevent the possibility of electric shock, connect the cables with the power turned OFF. Note • Connect the RD pin to the SD (TD) pin on the PC (converter) end and the SD pin to the RD pin on the PC end.
  • Page 33 3.2 Terminal Arrangement and Signal Names and the Connection Procedure of the RS-422A/485 Communication Interface (The following figure illustrates the case when the host computer’s interface is RS-232.) Host * When our communication converter COM-K (sold separately) be used. computer Terminator (built-in) 120 Ω...
  • Page 34 3.2 Terminal Arrangement and Signal Names and the Connection Procedure of the RS-422A/485 Communication Interface (The following figure illustrates the case when the host computer’s interface is RS-232.) Host computer * When our communication converter COM-K (sold separately) be used. Terminator (Built-in) 120 Ω, 1/2 W or more Terminator (externally attached) RS-422A/485...
  • Page 35 3.2 Terminal Arrangement and Signal Names and the Connection Procedure of the RS-422A/485 Communication Interface • When Instruments That Support Only the RS-422A Interface Exist in the System When using the four-wire system, up to 32 recorders can be connected to a single host computer. However, this may not be true if instruments that support only the RS-422A interface exist in the system.

  • Page 36: The Bit Structure Of One Character

    The Bit Structure of One Character and the Operation of the Receive Buffer The Bit Structure of One Character The serial interface on the recorder communicates using start-stop synchronization. In start-stop synchronization, a start bit is added every time a character is transmitted. The start bit is followed by the data bits, parity bit, and stop bit.

  • Page 37: Modbus Slave Protocol Specifications

    Modbus Slave Protocol Specifications The Modbus slave protocol specifications of the recorder are as follows: Item Specifications Transmission medium RS-422A/485 Flow control None only Baud rate Select from 1200, 2400, 4800, 9600, 19200, or 38400 [bps] Start bit Fixed to 1 bit Stop bit Fixed to 1 bit Parity check...

  • Page 38: Registers

    3.4 Modbus Slave Specifications Registers The registers for using the Modbus slave protocol are listed below. The register data does not contain unit and decimal point position information. Set them on the Modbus master. Binary values are stored to the register in order from the highest byte. Input register Data 30001...

  • Page 39: Modbus Error Response

    Communication input data of C01 40024 Communication input data of C24 • Pen model: C01 to C08, dot model: C01 to C12 (SBR-EW100), C01 to C24 (SBR-EW180) • The data is a 16-bit signed integer. Modbus Error Response The recorder returns the following error codes to the master device. For the error messages related to communications that the recorder displays, see appendix 4.

  • Page 40: Setting The Serial Interface

    Setting the Serial Interface The serial interface must be configured. Setup Items RS422/485 Address Baud rate Data length Parity Protocol Procedure For a description of the basic operations, see “Basic Key Operations” on page v. Entering Basic Setting Mode Hold down the key for 3 seconds to display the Setting mode screen.
  • Page 41 3.5 Setting the Serial Interface Explanation • Address Select the address from the following range. 01 to 32 • Baud rate Select the baud rate from the following: 1200, 2400, 4800, 9600, 19200, or 38400 • Data length Select the data length from below. To output data in BINARY format, be sure to set the data length to 8 bits. 7 or 8 •...

  • Page 42: Chapter 4 Commands

    Chapter 4 Commands Command Syntax The syntax of the setting/basic setting/output commands (see sections 4.4 to 4.7) of the instrument is given below. ASCII codes (see appendix 1) are used for the character codes. For the Maintenance/Test command syntax, see section 4.9. For the Instrument Information server command syntax, see section 4.10.

  • Page 43: Response

    4.1 Command Syntax • Query • A question mark is used to specify a query. • By placing a query after a command or parameter, the setting information of the corresponding command can be queried. Some commands cannot execute queries. For the query syntax of each command, see sections 4.4 to 4.7.

  • Page 44: A List Of Commands

    Sets the brightness of the display (VFD) and internal Run mode 4-14 illumination. Sets the DST. Run mode 4-14 Sets the DST. (Can be used on the SBR-EW100 with system Run mode 4-15 version 1.02 or earlier) Sets the computation constant (/M1 option). Run mode 4-15 Sets the timer used in TLOG computation (/M1 option).

  • Page 45: Basic Setting Commands

    4.2 A List of Commands Basic Setting Commands Note • In order to activate the settings that are changed using the basic setting commands, the settings must be saved using the YE or XE command. • The settings that are returned in response to a query in the basic setting mode will contain the new settings even if they are not saved.

  • Page 46: Control Commands

    4.2 A List of Commands Control Commands Command Function Execution Mode Administrator User Page Name Switches the execution mode. All modes 4-25 Starts/Stops recording. Run mode 4-25 DISP Switches the screen/switches the channel. Run mode 4-25 FUNC A K Executes alarm acknowledge (AlarmACK) Run mode 4-25 FUNC T L...

  • Page 47: Maintenance/Test Commands

    4.2 A List of Commands Maintenance/Test Commands These commands can be used only when using Ethernet communications. Command Name Function Execution Mode Administrator User Page Disconnects the connection between other instruments. All modes 4-29 c l o s e Outputs connection information. All modes 4-29 c o n...

  • Page 48: Parameter Values

    Parameter Values This section explains frequently used parameters. Input Range The following tables show the input types (VOLT, TC, RTD, DI, and 1-5V), range types, and the ranges for the leftmost and rightmost values of the span. • DC Voltage (VOLT), Square Root (SQRT), Difference between Channels (DELTA) Range Type Parameter for...

  • Page 49: Miscellaneous

    SBR-EW180 : 01 to 24 Computation channel: SBR-EW100 : 0A, 0B, 0C, 0D, 0E, 0F, 0G, 0J, 0K, 0M, 0N, 0P SBR-EW180 : 0A, 0B, 0C, 0D, 0E, 0F, 0G, 0J, 0K, 0M, 0N, 0P, 1A, 1B, 1C, 1D, 1E, 1F, 1G, 1J, 1K, 1M, 1N, 1P Relay Number (/A1, /A2, /A3, /A4, and /A5 Options) •...
  • Page 50 4.3 Parameter Values Chart Speed on the Pen Model mm/h 1000 1080 1200 1350 1440 1500 1600 1800 2000 2160 2250 2400 2700 2880 3000 3600 4000 4320 4500 4800 5400 6000 7200 8000 9000 10800 12000 IMSBR08-E2...

  • Page 51: 4.4 Setting Commands

    4.4 Setting Commands Description • This command cannot be specified while 4.4 Setting Commands computation is in progress. • For p3 and p4, enter an integer value of 5 digits or Sets the input range. less according to the table in section 4.3. The decimal position is fixed to the position indicated in When setting channels to skip the table in section 4.3.
  • Page 52 4.4 Setting Commands Description • This command cannot be specified while Example Calculate the sum of channel 01 and 02 on computation is in progress. computation channel 0A. Set the leftmost and • Set p4 according to the table in section 4.3. rightmost values of span to –10.00 and 15.00, •...
  • Page 53 4.4 Setting Commands p 6 Relay output • On models with the computation function (/M1 Relay ON option), alarms can be set on computation O F F Relay OFF channels. p 7 Relay number (µR10000: I01 to I06, SBR-EW180 • When the computation equation setting (SO : I01 to I06, I11 to I16, I21 to I26, I31 to I36) command) is turned OFF, p3 cannot be turned Query...
  • Page 54 0 6 , O N , O F F p 1 Channel number Description On models with the computation function (/M1 option), p 2 Leftmost position of the zone (SBR-EW100: 0 to computation channels can be specified. 95, SBR-EW180: 0 to 175) [mm]...
  • Page 55 4.4 Setting Commands Sets the tag. Sets the input filter (pen model). Syntax ST p1,p2<terminator> p 1 Channel number Syntax SF p1,p2<terminator> p 2 Tag string (up to 7 characters) p 1 Channel number Query p 2 Filter time constant (OFF, 2s, 5s, 10s) S T [ p 1 ] ? Example...
  • Page 56 0 B , 1 , O F F • The TD command can be used on the SBR-EW100 Description • This command cannot be specified while and SBR-EW180 with system version 1.11 or later. computation is in progress.
  • Page 57 6 C H b a r g r a p h 1-channel digital display + 4 channel bar 6-channel bar graph display (SBR-EW100 graph display (tag, pen model) dot model) p 3 Displayed channel switching interval...
  • Page 58 Example Assign the display in which different screens can be Chart speed (SBR-EW100) assigned to the top and bottom sections to screen 09. T I M E / C h a r t s p e e d...

  • Page 59: 4.5 Basic Setting Commands

    4.5 Basic Setting Commands p 5 Hold/Not hold the relay 4.5 Basic Setting Commands Hold the relay output until an H O L D alarm acknowledge operation is executed • In order to activate the settings that are changed Reset the relay output when the N O N H O L D using the basic setting commands, the settings alarm is cleared.
  • Page 60 4.5 Basic Setting Commands Sets the burnout detection. Sets the pen offset compensation (pen model). Syntax XB p1,p2 <terminator> p 1 Channel number Syntax UO p1<terminator> p 2 The procedure taken when a sensor burnout is p 1 Pen offset compensation ON/OFF (ON, OFF) detected Query U O ?
  • Page 61 4.5 Basic Setting Commands Sets the display mode of p 4 Periodic printout mode the bar graph. Disable periodic printout O F F Print instantaneous values. I N S T Syntax UB p1,p2<terminator> Print the report data over the R E P O R T p 1 Channel number interval.
  • Page 62 4.5 Basic Setting Commands D/M/Y: (example) 31/08/2005 YMD H:M:S Month Day Year Hour:Minute: D.M.Y: (example) 31.08.2005 Second M.D.Y: (example) Aug.31.2005 No time printout N o n e Query p 3 Time printout format of the record start time X N ? Example Set to the "2005/08/31"...
  • Page 63 4.5 Basic Setting Commands Example Set the address to 2, the baud rate to 9600, the data Description Each time the interval specified by p3 elapses from the length to 8, the parity check to ODD, and the NORMAL time the computation is started, the operations set with protocol.
  • Page 64 3 Record position adjustment value O N , 1 9 2 . 1 6 8 . 0 . 1 When p1 = ZERO SBR-EW100: An integer Description The settings specified by this command and saved between 0 and 70...
  • Page 65 When p1 = H y s t e r e s i s An integer between –7 to 7 When p1 = ZERO SBR-EW100: An integer between 0 and 15 SBR-EW180: An integer between 0 and 50 When p1 = FULL SBR-EW100: An integer between –30 to 30...

  • Page 66: 4.6 Control Commands

    4.6 Control Commands Starts/stops/resets 4.6 Control Commands computation (/M1 option). Syntax TL p1<terminator> Switches the execution mode. p 1 Operation type Computation start Syntax DS p1<terminator> Computation stop p 1 Mode Computation reset Run mode Example Start the computation. Basic Setting mode Example Switch to Basic Setting mode.

  • Page 67: 4.7 Output Commands

    4.6 Control Commands/4.7 Output Commands Clears the message printout 4.7 Output Commands buffer. Syntax MC p1<terminator> Sets the byte output order. p 1 Clear the message printout buffer (0) Example Clear the message printout buffer. Syntax BO p1<terminator> p 1 Byte order Outputs the data MSB first.
  • Page 68 4.7 Output Commands Example Disconnect the connection. Example Outputs the most recent periodic printout data of channel 01 to 04. I n s t , 0 1 , 0 4 Outputs decimal point position, Description Tlog1 and Tlog2 are valid on models with the unit information, and setup data.

  • Page 69: Rs-422A/485 Dedicated Commands

    4.7 Output Commands/4.8 RS-422A/485 Dedicated Commands • Be sure to set p2 and p3 so that p3 is greater than 4.8 RS-422A/485 or equal to p2. Dedicated Commands • For the output flow of FIFO data, see appendix 4. Outputs status information. ESC O Opens the instrument.

  • Page 70: Maintenance/Test Commands

    4.9 Maintenance/Test Commands Outputs Ethernet 4.9 Maintenance/Test statistical information. Commands (Available Syntax eth<terminator> when using the Example maintenance/test server function via Ethernet 04/10/01 12:34:56 communications) Ethernet Statistics close Disconnects the connection Name In Pkt In Err Out Pkt Out Err 16 Coll between other instruments.

  • Page 71: Server Function Via Ethernet Communications)

    4.10 Instrument Information Output Commands (Available when using the instrument information server function via Ethernet communications) 4.10 Instrument Information T C P : k e e p a l i v e Output Commands Keepalive check cycle. T C P : c o n n e c t s (Available when using the Total number of connections established.

  • Page 72: Chapter 5 Responses

    Chapter 5 Responses Response Syntax The following table shows the types of responses for various commands described in the previous chapter. The recorder returns a response (affirmative/negative response) to a command that is separated by a single terminator. The controller should follow the one command to one response format. Function Command Response...

  • Page 73: Ascii Output

    5.1 Response Syntax • Example E2 02:001 ASCII Output The following types of ASCII data are available. For the data formats, see section 5.2. Setting data, basic setting data, decimal position/unit information, measured/computed data, report data generated by the periodic printout, status information, and user information •...
  • Page 74 5.1 Response Syntax • Flag Name (Abbreviation) Flag Flag Meaning of the Flag Output byte order Existence of a checksum – – – – – – – – – – – – – – – Reserved – – Fixed to 1. •...
  • Page 75 5.1 Response Syntax If the data length of the buffer is odd, a “0” is padded so that it is even. (1) through (6) are summed as unsigned two-byte integers (unsigned short). If the digit overflows a “1” is added. Finally, the result is bit- wise inverted.

  • Page 76: Rs-422A/485 Dedicated Commands And Responses

    5.1 Response Syntax RS-422A/485 Dedicated Commands and Responses The following table shows dedicated commands for the RS-422A/485 interface and their responses. Command Syntax Meaning Response Open the instrument. • Response from the instrument with the ESC  O_xx  CRLF specified address ESC ...

  • Page 77: Output Format Of Ascii Data

    Output Format of ASCII Data The following types of ASCII data are available. • Setting data/Basic Setting data • Decimal point position/unit information • Measured/computed data • Report data generated by the periodic printout • Status information • User information Note The “CRLF”...

  • Page 78: Decimal Point Position/Unit Information

    OFF for a computation channel) Channel type 0: Measurement channel A: Computation channel Channel number SBR-EW100: 01 to 06, 0A to 0P SBR-EW180: 01 to 24, 0A to 1P Unit information (6 characters, left-justified) uuuuuu mV____: mV V_____: V ^C____: °C...

  • Page 79: Measured/Computed Data

    E: Error Channel type 0: Measurement channel A: Computation channel Channel number SBR-EW100: 01 to 06, 0A to 0P SBR-EW180: 01 to 24, 0A to 1P Alarm status (level 1) Alarm status (level 2) Alarm status (level 3) Alarm status (level 4)
  • Page 80 5.2 Output Format of ASCII Data Each status is set to H, L, h, l, R, r, T, t, or space. H: high limit alarm, L: low limit alarm, h: difference high-limit alarm, l: difference low-limit alarm, R: high limit on rate-of- change alarm, r: low limit on rate-of-change alarm, T: delay high limit alarm, t: delay low limit alarm, space: no alarm Unit information (6 characters, left-justified)

  • Page 81: Report Data Generated By The Periodic Printout

    Error data occurrence during reporting: E (yes) or space (no) ±over data occurrence during reporting: O (yes) or space (no) All spaces Channel number SBR-EW100: 01 to 06, 0A to 0P SBR-EW180: 01 to 24, 0A to 1P Channel type (0, A) 0: Measurement channel...
  • Page 82 5.2 Output Format of ASCII Data dddddEf pp_f dddddEf pp_f dddddEf pp_f dddddEf pp_f dddddddd The data is output in the following order: most recent value, minimum value, maximum value, average value, and sum value. dddddEf Most recent value, minimum value, maximum value, and average value of the measurement channel ddddddddEf Sum value of the measurement channel or the most recent...

  • Page 83: Status Information

    5.2 Output Format of ASCII Data Status Information • The IS command is used to output the data. • The operation status of the recorder is output • For details on the status information, see section 6.2, “The Bit Structure of the Status Information.” •...

  • Page 84: Output Format Of Binary Data

    Output Format of BINARY Data This section describes the output format of the BINARY data that is disclosed. For the BINARY output format, see “BINARY Output” on page 5-2. For other BINARY data types, see “Identifier” on page 5-3. The measured data is output using signed 16-bit integer; the computed data is output using signed 32-bit integer. These integers can be understood as physical values by adding the decimal point and the unit.
  • Page 85 5.3 Output Format of BINARY Data • Flag The meanings of the flags are given on the table below. The flags are valid during FIFO data output. The flags are undefined for other cases. Flag Flag Meaning of the Flag –...

  • Page 86: Chapter 6 Status Information

    Chapter 6 Status Information Status Information and Filter The following figure illustrates the status information and filter on the recorder. 4 bytes Status information Filter Condition register • When a status indicated on the following page is entered, the corresponding bit in the condition register is set to “1.”...

  • Page 87: The Bit Structure Of The Status Information

    The Bit Structure of the Status Information The following four groups of status information are output in response to a status information output request using the IS command. For the output format, see “Status Information” in section 5.2, “Output Format of ASCII Data.” Status Information 1 Name Description...

  • Page 88: Appendix

    Appendix Appendix 1 ASCII Character Codes The table below contains the ASCII character codes of characters that can be used. The table below shows characters each command can use. Command Used for Characters Unit Alphanumeric characters, signs, and space Alphanumeric characters, signs, and space Message Alphanumeric characters, signs, and space Host/Domain name...

  • Page 89: Appendix 2 Output Flow Of Fifo Data

    Appendix 2 Output Flow of FIFO Data The recorder has a dedicated internal memory for outputting measured/computed data. This memory is structured as a FIFO (First-In-First-Out). Measured/computed data are constantly acquired to the internal memory at the specified acquiring interval (FIFO acquiring interval, set with the FR command). By using this function, it is possible to read measured/computed data that have been saved at the specified intervals regardless of the frequency at which the PC periodically reads the measured/computed data.
  • Page 90 Appendix 2 Output Flow of FIFO Data Example in which the FIFO acquiring interval on the recorder is set to 1 s and the measured data from channel 01 to 06 are continuously output (logging function) Command to send START Command description Received response data Send command...

  • Page 91: Appendix 3 Login Procedure

    Appendix 3 Login Procedure When using the Setting/Measurement server or the Maintenance/Test server via the Ethernet interface (/C7 option), you must log into the recorder from the PC. If you complete the procedure successfully up to login complete in the following figure, the commands in chapter 4 become functional. When using the login function Connect Within the number of...
  • Page 92 Appendix 3 Login Procedure When not using the login function Login as “admin” or “user.” • The user name “admin” can be used to login to the recorder as an administrator. • The user name “user” can be used to access the recorder as a user. Connect Within the number of E1 421...

  • Page 93: Appendix 4 A List Of Error Messages

    Appendix 4 A List of Error Messages There are cases in which error codes and messages are displayed on the screen during operation. The error messages and their description are listed below. Setting Errors Code Message Explanation/Countermeasures System error. Contact your nearest RKC dealer. Incorrect date or time setting.

  • Page 94: Operation Errors

    Appendix 4 A List of Error Messages Code Message Explanation/Countermeasures All space or ‘quit’ string cannot be specified. – The key-lock release password is incorrect. Enter the correct password. This key is locked. – Password is incorrect. Enter the correct password. IP address doesn’t belong to class A, B, or C.

  • Page 95: Warning Messages

    Appendix 4 A List of Error Messages Code Message Explanation/Countermeasures Input username. – Input password. – Select username from ‘admin’ or ‘user’. If the recorder is configured not to use the user name and password, use user names ‘admin’ or ‘user’. Login incorrect, try again! –...

  • Page 96: Index

    Index host ....................4-30 Symbols Page IF ...................... 4-26 ip4-30 1-5V input low-cut .................. 4-21 IS ...................... 4-28 LS ....................4-25 Page M C ....................4-26 MP ....................4-25 A/D integral time ..................4-18 MS ....................4-25 address ....................3-12 net ....................
  • Page 97 Index YC ....................4-26 frequently used parameters ..............4-7 YD ....................4-23 functional construction (ethernet) ............1-1 YE ....................4-24 functional construction (RS-422A/485) ........... 1-4 YK ....................4-23 YN ....................4-23 Page YQ ....................4-23 YS ....................4-21 help ......................4-29 command syntax ..................
  • Page 98 Index Page Page parameters ....................4-1 tag ......................4-14 parity check .................... 3-12 temperature unit ..................4-21 partial expanded recording ............4-13, 4-20 terminator ..................3-6, 4-2 password ....................2-9 time printout format ................. 4-21 pen offset compensation ................ 4-19 timeout ...................
  • Page 99 第 3 版: 2002 年*月...
  • Page 100 Subkect to change without notice due to design changes. The first edition : JAN.2006 [IMQ00] HEADQUARTERS: 16-6, KUGAHARA 5-CHOME, OHTA-KU TOKYO 146-8515 JAPAN PHONE: 03-3751-9799 (+81 3 3751 9799) E-mail: info@rkcinst.co.jp RKC INSTRUMENT INC. FAX: 03-3751-8585 (+81 3 3751 8585) JAN.2006 IMSBR08-E2...
