ATCOM IPPBX IP4G User Manual page 53

IPPBX IP4G User Manual
Set the destination port range for connection. The main protocols and default ports IPPBX uses for each
application are list below:
HTTP
HTTPS
SIP
SIP
RTP
IP
Set source IP of connection.Format of IP: IP/mask
For example:
192.168.1.156/255.255.255.255 for IP 192.168.1.156
216.207.245.47/255.255.255.255 for IP 216.207.245.47
192.168.1.156/255.255.255.0 for network 192.168.1.0/24
Mac Address
Set source Mac of connection. Either IP or Mac Address must be set.
Action
Accept: Accept the access from remote hosts.
Drop: Drop the access from remote hosts.
3) Auto Defense
Limit connections from remote hosts.
Port
TCP:80
TCP:443
UDP:5060
TCP:5060
UDP:10000-20000
