For example: Once set Dial Pattern: 2XX Strip: 0, that means any calls to 200-299 will be forwarded out. Please
do not simply set it to X., otherwise all telephone numbers with 2 or 2+ digits will be matched, this outbound route
probably affect your interior calls, unless your local extensions is just a single figure.
Strip: The number of digits that will be stripped from the front of the dialing string before the call is placed via
Selected Trunks. See example in Chapter 6.
Prepend these digits: Allows the user to specify digits that are prepended before the call is placed via the trunk.
Password: Authentication for Selected Extensions before dialing out.
Outbound Extension Selection: Select extensions which can dial out with this outbound route. In my case, only
6000 and 6001 can dial out with this trunk.
Outbound Trunk Selection: Select trunks which calls are forwarded out through.

Make inbound calls

4.4
Go to PBX Settings -> Inbound Routes, click to add an inbound route.
1) General
Caller ID
Define the Caller ID number to be matched on incoming calls. Leave this field blank to match any or no CID info.
Special characters described in chapter 4.3 can be used here as same.
DID number
Define the expected DID number if your trunk passes DID on incoming calls. Leave this blank to match calls with
any no DID info. The DID for SIP trunk is usually as same as the account (others can only dial the account
number to dial into PBX), then just leave it blank is OK .
Extension
Define the extension for DID number. This field is usually unavailable for most VoIP trunk, if you VoIP provider
support DID, you can set it. You can only input number and '-' in this field, and the format can be XXX or
XXX-XXX. The count of the number must be only one or equal the count of the DID number. Up to 100 DID
numbers can be set.
For example: Set DID number: 6000-6010，Extension: 6000，All inbound calls to 6000-6010 will be forwarded to
extension 6000. Set DID number: 6000-6010, Extension: 6000-6010, inbound calls to 6000-6010 will be
forwarded to corresponding extension.
