7.11 IAX Settings

UDP Port
Port use for IAX2 registrations, Default is 4569.
Bandwidth
Low/medium/high with this option you can control which codec to be used.
Min Registration Time
Minimum duration (in seconds) of a IAX2 registration. Default is 60 seconds.
Max Registration Time
Maximum duration (in seconds) of a IAX2 registration. Default is 1200 seconds.

8. Audios

8.1 Music On Hold

Manage audio files for Music On Hold, the format should be .WAV (16 bit, mono 8000 Hz) and .GSM, the size
should less than 4 MB.

8.2 Custom Prompts

Manage prompts used for Voice Menu. It can be recorded by extensions or uploaded from local PC, the format
should be .WAV (16 bit, mono 8000 Hz) and .GSM, the size should less than 4 MB

8.3 Language Setting
