IPPBX IP4G User Manual
Show the model of this IPPBX
Firmware Version
Show the firmware version
System Uptime
Show the time how long the system has been running
System Current Time
Show the current time
2) Network
Show the network setting of IPPBX
3) Peripheral
Show what kinds of / how many modules are detected.
2. Create local extensions and make interior calls
There are two kinds of extensions in IPPBX: SIP extensions and IAX extensions.
3.1 VOIP extensions
A VOIP extension is a SIP/IAX Account that allows an IP Phone or an IP SoftPhone client to register on IPPBX. It
can be created / modified / deleted one by one or in batch.
3.2.1 Add new extensions
a. Add single extension
Click
to add an extension
NOTE: VOIP extension number range is defined in PBX Settings -> Options -> Extension Preference,
changing it can create extensions in others number range.
1) General
Type
Extension type: SIP,IAX or SIP/IAX.
SIP – The extension sends and receives calls using the VoIP protocol SIP.
IAX -The extension sends and receives calls using the VoIP protocol IAX.
Name
A character-based name for this extension, i.e. 'Bob Jones'
Extension
Extension number, i.e. 6000, it is associated with this particular user / phone.
Password
~ 10 ~
ATCOM TECHNOLOGY CO., LIMITED
