Fire Sense PH08-SA Instruction Manual & Parts List

Hide thumbs
Table of Contents

Advertisement

Quick Links

Patio Heater
Model:
Instruction Manual & Parts List
INSTALLER: Please leave this manual for the consumer.
CONSUMER: Please retain this manual for future reference.
MANUFACTURER: Changzhou Wellife Furnace Co., Ltd.
-
PH08-SA, PH08-SSA
Item #: 60804
WARNING: For outdoor use only.

FOR YOUR SAFETY

If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, immediately call
gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors or liquids in the
vicinity of this or any other appliance.
An LP-cylinder not connected for
use shall not be stored in the
vicinity of this or any other
appliance.
3177588
1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PH08-SA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fire Sense PH08-SA

Summary of Contents for Fire Sense PH08-SA

  • Page 1 Patio Heater PH08-SA, PH08-SSA Model: Item #: 60804 WARNING: For outdoor use only. FOR YOUR SAFETY If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, immediately call gas supplier.
  • Page 2 Tools and parts needed for assembly DANGER CARBON MONOXIDE HAZARD This appliance produce carbon monoxide which has no odor. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home.
  • Page 3 PRECAUTIONS NOTE: PLEASE READ THE FOLLOWING SAFETY RULES WARNING: This heater must only be used outdoors. Using this product in an enclosed area may cause injury, death or property damage. Only use in a well-ventilated space. Do not use in a building, garage, or any other enclosed area.
  • Page 4 PRECAUTIONS CHECK THE HEATER IMMEDIATELY IF ANY OF THE FOLLOWING EXIST: 1. The smell of gas in conjunction with extreme yellow colored tips of the burner flames. 2. The heater does not reach temperature. 3. The burner makes a popping noise during use (a slight popping noise is normal when the burner is extinguished after using).
  • Page 5 ASSEMBLY 1. Base assembly with tank control housing 2. 2pcs wheels 3. Handle 4. 2pcs glass tube fixed parts (one for top, one for bottom) 5. 2pcs glass tube 6. Glass tube connector 7. 4pcs lower support 8. 4pcs upper support 9.
  • Page 6 ASSEMBLY WARNING: This appliance requires installation by a competent person. Proper assembly is the responsibility of the installer. Step 1 Attach the wheels (2) to the base assembly (1)with 8pcs M6x18mm bolts (23) and 8pcs M6 nuts (24). Step 2 Attach the handle (3) to the back panel of the base assembly(1) with 4pcs M6x12mm bolts (17).
  • Page 7 ASSEMBLY Step 3 Attach one of the glass tube fixed parts (4) on the base assembly (1) with 3pcs M4x8mm screws (20). Step 4 Screw the 4pcs lower support (7) into the holes located on the top of the base assembly (1).
  • Page 8 ASSEMBLY Step 5 Put the 4pcs of the support connector (9) onto the tops of the 4 lower supports (7). Step 6 Screw the 4 upper supports (8) onto the 4 lower supports (7).
  • Page 9 ASSEMBLY Step 7 Fit one piece of the glass tube (5) into the glass tube fixed part (4) on top of the base assembly (1). Insert the glass tube connector (6) into the glass tube piece already attached to the base assembly and then lower the second piece of glass tube over the glass tube connector.
  • Page 10 ASSEMBLY Step 9 Put the assembled upper plate from Step 8 on top of the assembled support connectors and use 4pcs M12 screws (15) to secure it. Step 10 Attach 4pcs mesh guard (10) on the lower support connectors. NOTE: The long side will connect with the base assembly.
  • Page 11 ASSEMBLY Step 11 Attach 4pcs mesh guard (10) on the upper support connectors. Step 12 Attach 4pcs mesh fixed parts (13) on the assembled upper plate with 4pcs M4x8mm screws (22). 11 -...
  • Page 12 ASSEMBLY Step 13 Attach the top reflector (12) on the assembled upper plate with 3pcs 3/16’’ screws (19) and 4pcs M5x10mm bolts (16). Step 14 Open the front panel of base assembly (1). Attach 3pcs gas cylinder fixed parts (14) on the base with 6pcs M6x12mm bolts (18).
  • Page 13 ASSEMBLY Step 15 Connect the regulator (Preassembled with the burner) to the LPG cylinder and hand tighten, then put gas cylinder on the base. Warning: When connecting the gas cylinder and regulator, make sure the connection is tight and always check for leaks. Please see page 14 “Check for Leak”...
  • Page 14 ASSEMBLY Check for Leak Your patio heater has been checked at all factory connections for leaks, but you should always check when you attach the LPG cylinder. To check for leaks, follow these instructions: --Assemble all gas connections; --Connect regulator assembly to the propane tank; --Make sure the heater valve is turned OFF.
  • Page 15 ASSEMBLY NOTE: 1) The cylinder must be provided with a shut off valve terminating in a LPG supply cylinder valve outlet specified, as applicable, for connection NO 510 in the standard for compressed gas cylinder valve outlet and inlet connections, ANSI/CGA-v-1. 2) The cylinder supply system must be arranged for vapor withdrawal.

  • Page 16: Before Lighting

    OPERATION WARNING: DO NOT attempt to operate the heater until you have read and understand all precautions. Failure to do so can result in serious personal injury, death or property damage. Before Turning Gas Supply ON. Your heater was designed and approved for OUTDOOR USE ONLY. DO NOT use it inside a building or any other enclosed area.
  • Page 17 OPERATION LIGHTING INSTRUCTIONS TO TURN ON THE HEATER. 1. Turn the control knob “OFF”. 2. Slowly open the gas cylinder valve. 3. Press and turn the control knob to “ ” position and hold for 30 seconds. While holding down the control knob, press the igniter several times until the pilot flame ignites.
  • Page 18 LOCATION OF HEATER WHILE IN USE CAUTION: WHEN CERTAIN MATERIALS OR ITEMS ARE LEFT UNDER THIS HEATER WHILE IN USE, THEY WILL BE SUBJECT TO RADIANT HEAT AND COULD BE SERIOUSLY DAMAGED. This heater is to be used for the heating of outdoor patios, decks, spas, pool, and open working areas.
  • Page 19 MAINTENANCE CLEANING AND MAINTENANCE WARNING FOR YOUR SAFETY DO NOT touch or move To enjoy years of outstanding performance from your heater for at least 45 heater, make sure you perform the following maintenance minutes after use. on a regular basis: Allow all burner elements to cool before touching.
  • Page 20 TROUBLESHOOTING Problem Problem cause solution Pilot will not light Gas valve may be Turn the gas valve ON Tank fuel empty Refill LP gas tank Air in supply system Purge air from lines Loose connection Check all fittings Pilot will not stay on Debris around pilot Clean dirty area Loose connection Tighten connection...
  • Page 21 Distributed By:    Well Traveled Living  Web: www.wtliving.com  716 S 8  Street  Email: cservice@welltraveled.net  Amelia Island, FL 32034  Toll Free: 866‐WTL‐SUPP  1 YEAR LIMITED WARRANTY – Customers in the Continental US All components are warranted for a period of 1 year after date of purchase by the original owner against defects in materials and workmanship under normal use.
