Outdoor Patio Fireplace


















WARNING



      FOR YOUR SAFETY




For Outdoor Use Only

(outside any enclosure)

Save these instructions for future reference.**
**
28" Round Fire Pit
MFG Item# 01471
WARNING
1. Improper installation, adjustment, alteration,
    service or maintenance can cause injury or property
    damage.
2.  Read the installation, operation, and
      maintenance instructions thoroughly before installing
      or servicing this equipment.
3. Failure to follow these instructions could result in fire
    or explosion, which could cause property
    damage, personal injury, or death.
***IMPORTANT NOTICE***
‐Do NOT return to place of purchase.
For customer service and warranty issues
contact our Toll Free Hotline at:
(866)‐985‐7877 OR
Email: cservice@welltraveled.net
Hotline hours : Mon. – Fri. 9:00 am – 6:00 pm (EST)

      FOR YOUR SAFETY:
U.S. Patents 5,836,298 and D420,115

Advertisement

loading
Need help?

Need help?

Do you have a question about the 28inch Round Fire Pit and is the answer not in the manual?

Questions and answers

Summary of Contents for Fire Sense 28inch Round Fire Pit

  • Page 1 Outdoor Patio Fireplace 28” Round Fire Pit MFG Item# 01471                                       WARNING  WARNING         FOR YOUR SAFETY:              FOR YOUR SAFETY    1. Improper installation, adjustment, alteration,        service or maintenance can cause injury or property    ...
  • Page 2 WARNING FOR YOUR SAFETY  1. This appliance is for outdoor use only, and should NOT be used in a building, garage, or any other enclosed area.  2. Do NOT use this outdoor fireplace for indoor heating. TOXIC carbon monoxide fumes can accumulate and cause asphyxiation.  3. This outdoor fireplace is NOT for commercial use.  4. This outdoor fireplace is NOT to be operated by children.  5. This outdoor fireplace is NOT to be used on boats or recreational vehicles.  6. Always use in accordance with all applicable local, state and national codes. Contact your local fire department for details on        outdoor burning.  7. When using this outdoor fireplace, exercise the same precautions you would with any open fire.  8. The use of alcohol, prescription or non‐prescription drugs may impair the consumer’s ability to properly assemble or safely         operate this outdoor fireplace.  9. Do NOT use this outdoor fireplace without reading the entire “Owner’s Manual”.  10.This outdoor fireplace is for use with dry, seasoned hardwood. It will burn hotter, more completely and create less smoke.  11. Do NOT burn charcoal briquets, lump charcoal, manufactured logs, driftwood, trash, leaves, paper, cardboard, plywood,        painted, stained or pressure treated wood. Avoid using softwoods such as pine or cedar that can throw sparks. Before using          this outdoor fireplace, fill with several pounds of sand to help insulate the bottom bowl from the fire.  12. Do NOT alter this outdoor fireplace in any manner.  13. Do NOT use this outdoor fireplace until it is COMPLETELY assembled and all parts are securely fastened and tightened.  14. Do NOT store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliance.  15. Do NOT store or use an LP gas cylinder within 10 feet (3.05 m) of this outdoor fireplace while it is in operation.  16. Do NOT use this outdoor fireplace near automobiles, trucks, vans or recreational vehicles,  17. Do NOT use in an explosive atmosphere. Keep outdoor fireplace area clear and free from combustible materials, gasoline and           other flammable liquids.  18. Do NOT use this outdoor fireplace under any overhead or near any unprotected combustible constructions. Avoid using near         or under overhanging trees and shrubs.  19. Always use this outdoor fireplace on a hard, level non‐combustible surface such as concrete, rock or stone. An asphalt or        blacktop surface may not be acceptable for this purpose. Do NOT use on wooden decks.  20. Always empty this outdoor fireplace before each use. Leave a thin layer of ash to protect the bottom.  21. Do NOT wear flammable or loose clothing when operating this outdoor fireplace.  22. Do NOT use in windy conditions.  23. Do NOT use this outdoor fireplace unless spark guards are securely in place.  24. Do NOT use gasoline, kerosene, diesel fuel, lighter fluid or alcohol to light or relight fires.  25. Keep all electrical cords away from hot fireplace.  26. All surfaces of this outdoor fireplace are hot when in operation. To avoid burns, do NOT touch fireplace until it has         completely  cooled unless you are wearing protective gear (potholders, gloves, BBQ mittens, hot pads, etc). Never touch          ashes or coals to see if they are hot.  27. Do NOT leave a lit outdoor fireplace unattended, especially around children and pets.  28. Do NOT attempt to move or store this outdoor fireplace until all ashes and coals are completely extinguished.  29. Do NOT remove ashes or coals until they are completely and fully extinguished.  30. Use heat‐resistant gloves or hot pads when contacting handles. ...
  • Page 3: Instructions For Assembly

    Instructions for Assembly Tools needs for assembly (not included) Adjustable wrench, pliers & Philips screwdriver (not included) Parts List Hardware List Part Part Description Qty. Description Qty. U leg Lock Nut Leg stand 6 X 35 mm Bolt Handles 6 X 15 mm Bolt Bowl 6 mm Nut Grate...
  • Page 4 Before beginning assembly, be sure to empty the entire contents of carton and make sure all parts are present. Please discard packing appropriately. Step 1: Attach Handle & Lid Hanger to Lid Align holes in handle (3) with exterior holes in lid (11). Align holes of lid hanger (10) to interior holes in lid (11) and insert bolt (15).
  • Page 6 Step 3: Leg Assembly Insert the U leg (1) into the ends of the 2 – leg stands (2) and align holes. Insert bolt (14) through holes and attach nut (16). Repeat for other side. Insert axle (7) through the holes on the 2 – leg stands (2). Attach wheel (6) to end of axle (1) and secure with lock nut (13).
  • Page 8: Cleaning And Care

    CLEANING AND CARE     Congratulations on your purchase of this patio fireplace. This product is comprised of steel with an  enameled surface and mesh wire screen. Be sure to read ALL safety and operating instructions  contained in this manual.   Inspecting   This outdoor fireplace should be inspected on a regular basis to ensure product safety and longer  product life. Do NOT attempt to inspect this outdoor fireplace until the fire is COMPLETELY out.  1. Check handles to make sure they are secure.   2. Check components for any signs of damage or rust.  3. If damage to any component is detected, do NOT operate until repairs are executed.    CLEANING   This outdoor fireplace should be cleaned on a regular basis to promote safer use and longer product life.  NOTE: After repeated use, a slight discoloration of the finish may occur.   Do NOT attempt to clean this outdoor fireplace until the fire is COMPLETELY out.   Do NOT use over cleaner or abrasive cleaners as they will damage this product.   Do NOT clean any part of this outdoor fireplace in a self cleaning oven as it may damage the finish.   1. Wipe exterior surfaces with a mild dishwashing detergent or baking soda.   2. For stubborn surfaces use a citrus based degreaser and a nylon scrubbing brush.   3. Rinse clean with water.   4. Remove build‐up creosote from components with a chimney cleaning product.      STORAGE   Do NOT move or store this outdoor fireplace until the fire is COMPLETELY out.   1. Once the fire is out, coals are cold and the outdoor fireplace is cool to the touch, remove ashes and  properly dispose.   2. Cover outdoor fireplace with a durable vinyl cover designed to fit this unit.   3. Store assembled in a location away from children and pets.   NOTE: If you do not use a cover, store this outdoor fireplace in a dry location to maximize product life. ...
  • Page 9 Distributed By:    Well Traveled Living  Web: www.wtliving.com  716 S 8  Street  Email: cservice@welltraveled.net  Amelia Island, FL 32034  Toll Free: 866‐WTL‐SUPP  1 YEAR LIMITED WARRANTY – Customers in the Continental US All components are warranted for a period of 1 year after date of purchase by the original owner against defects in materials and workmanship under normal use.
