Item #: 01338, 01337, 01347, 60789, 60790
Instruction Manual & Parts List
INSTALLER: Please leave this manual for the consumer.
CONSUMER: Please retain this manual for future reference.
Manufacturer: Changzhou Wellife Furnace Co., Ltd.
-
Patio Heater
Model: PH09-S/ PH09-SS
WARNING: For outdoor use only.
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, immediately
call gas supplier.
Do not store or use gasoline or
other flammable vapors or liquids
in the vicinity of this or any other
appliance.
PLEASE
reference.
1 -
FOR YOUR SAFETY
FOR YOUR SAFETY
retain this manual for
Advertisement
Table of Contents
Related Manuals for Fire Sense 1337
Summary of Contents for Fire Sense 1337
- Page 1 Patio Heater Model: PH09-S/ PH09-SS Item #: 01338, 01337, 01347, 60789, 60790 Instruction Manual & Parts List INSTALLER: Please leave this manual for the consumer. CONSUMER: Please retain this manual for future reference. Manufacturer: Changzhou Wellife Furnace Co., Ltd. WARNING: For outdoor use only.
-
Page 2: Tools And Parts Needed For Assembly
TOOLS AND PARTS NEEDED FOR ASSEMBLY DANGER Improper installation, adjustment, WARNING: alteration, service or maintenance can cause injury or property damage. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment. WARNING: For Outdoor Use Only LPG cylinders to be used must be constructed and marked in according with US DOT specifications Storage indoors is permissible only if the LPG... -
Page 3: Outdoor Use Only
NOTE: PLEASE READ THE FOLLOWING SAFETY RULES WARNING: This heater must only be used outdoors. Using this product in an enclosed area may cause injury, death or property damage. Only use in a well-ventilated space. Do not use in a building, garage, or any other enclosed area. - Page 4 CHECK THE HEATER IMMEDIATELY IF ANY OF THE FOLLOWING EXIST: 1. The smell of gas in conjunction with extreme yellow colored tips of the burner flames. 2. The heater does not reach temperature. 3. The burner makes a popping noise during use (a slight popping noise is normal when the burner is extinguished after using).
-
Page 5: Parts List
ASSEMBLY PARTS LIST 1. Burner assembly 2. 4 pcs mesh guard 3. Handle with 2 pcs M6 nuts and 2 pcs flat gaskets 4. Back panel 5. 5 pcs M4x10mm bolts, 5 pcs M4 flat gaskets, and 5 pcs M4 nuts to connect the burner assembly with back panel 6. - Page 6 WARNING: This appliance requires installation by a competent person. Proper assembly is the responsibility of the installer. Step 1 Use 6 pcs M6x12mm bolts and 6 pcs M6 nuts to connect 3 cylinder brackets on the base. The brackets will allow LPG cylinder to rest securely on base.
- Page 7 ASSEMBLY Step 3 Use 10 pcs M5x12mm bolts and 10pcs M5 nuts to connect 5 brackets with back panel, Attach the back panel on the base with 5 pcs M8x16mm bolts. Step 4 Attach the burner assembly to back panel with 5 pcs M4x10mm bolts, 5 pcs M4 flat gaskets, and 5 pcs M4 nuts.
- Page 8 ASSEMBLY Step 5 Attach the door panel to the back panel. Step 6 Attach the regulator to the burner assembly (see picture to the right) and tighten. Attach the regulator to the LPG cylinder (see below). Warning: Always make sure to check the connection for leaks before using the heater (see page 10).
- Page 9 ASSEMBLY Step 7 Attach mesh guards (4 pcs) to burner assembly as shown (see picture to right).
-
Page 10: Assembly And Operation
To check for leaks: Your patio heater has been checked at all factory connections for leaks, but you should always check when you attach the LPG cylinder. To check for leaks, follow these instructions: --Assemble all gas connections. --Connect regulator assembly to the propane tank. --Make sure the heater valve is turned OFF. - Page 11 NOTE: 1) The cylinder must be provided with a shut off valve terminating in a LPG supply cylinder valve outlet specified, as applicable, for connection NO 510 in the standard for compressed gas cylinder valve outlet and inlet connections, ANSI/CGA-v-1. 2) The cylinder supply system must be arranged for vapor withdrawal.
-
Page 12: Lighting Instructions
Before Lighting: Heater should be thoroughly inspected before each use. Have a qualified service person inspect the heater at least annually. If relighting a hot heater, always wait at least 5 minutes. This heater has been tested for quality assurance LIGHTING INSTRUCTIONS TO TURN ON THE HEATER. - Page 13 TO TURN OFF THE HEATER. 1. Press and turn the control knob to “OFF” position. 2. Turn off the valve on the LPG cylinder and disconnect the cylinder from the heater. OPERATION 13 -...
- Page 14 CAUTION: Avoid inhaling fumes emitted from the heater’s first use. Smoke and odor from the burning of oils used in manufacturing will appear. Both smoke and odor will dissipate after approximately 30 minutes. The heater should not produce thick black smoke. Note: The burner maybe be noisy when initially turned on.
- Page 15 LOCATION OF HEATER WHILE IN USE CAUTION: WHEN CERTAIN MATERIALS OR ITEMS ARE LEFT UNDER THIS HEATER WHILE IN USE THEY WILL BE SUBJECT TO RADIANT HEAT AND COULD BE SERIOUSLY DAMAGED. This heater is to be used for the heating of outdoor patios, decks, spas, pool, and open working areas.
-
Page 16: Cleaning And Maintenance
CLEANING AND MAINTENANCE To enjoy years of outstanding performance from your Heater, make sure you perform the following maintenance on a regular basis: 1. Keep exterior surfaces clean. Use warm soapy water for cleaning. Never use flammable or corrosive cleaning agents. While cleaning your heater, be sure to keep the area around the burner and pilot assembly dry at all times. - Page 17 Carbon deposits may create a fire hazard. Clean dome and engine with warm soapy water if any carbon deposits develop. n a salt-air environment (such as near an ocean), corrosion occurs more quickly than normal. If the heater is exposed to this type of environment, you should frequently check for corroded areas and repair them promptly MAINTENANCE...
-
Page 18: Troubleshooting
Pilot light assembly bent or not in correct location Manufacturer: Changzhou Wellife Furnace Co.,Ltd Tel: 86-519-83310111 Fax: 86-519-83311577 www.globalwellife.com Distributed By: Well Traveled Living P.O. Box 4 Amelia Island, FL 32034 800-766-9633 www.wtliving.com TROUBLESHOOTING solution Turn the gas valve ON... - Page 19 Distributed By: Well Traveled Living 716 S 8 Street Amelia Island, FL 32034 Toll Free: 866‐WTL‐SUPP 1 YEAR LIMITED WARRANTY – Customers in the Continental US All components are warranted for a period of 1 year after date of purchase by the original owner against defects in materials and workmanship under normal use. This warranty does NOT cover normal wear and weathering, assembly and/or maintenance OR use in a commercial application. At Well Traveled Living’s sole discretion, products under warranty will be repaired and/or replaced at no charge to the customer. Any returns sent back to Well Traveled Living must be sent via prepaid freight and in the original retail packaging. For warranty service contact Well Traveled Living at the address, phone numbers or internet site and email listed in this owner’s manual. Be sure to have your sales receipt, date of purchase and catalogue/model numbers available when calling. All warranty service will be coordinated by the Well Traveled Living’s, Amelia Island, Florida service center. This warranty is extended only to the original purchaser. Proof of purchase will be required before warranty service is rendered. The sales receipt is the only valid proof of purchase. This warranty only covers failures due to defects in materials ...
