Fire Sense PH01-S Instruction Manual

Outdoor patio heater
Hide thumbs Also See for PH01-S:
Table of Contents

Advertisement

Quick Links

ATTACH YOUR RECEIPT HERE
Serial Number ______________
Questions, problems, missing parts? Before returning to your
retailer, call our customer service hotline at 1-866-985-7877,
9 a.m. – 6 p.m., EST, Monday – Friday or email at
cservice@welltraveled.net.
Outdoor Patio Heater
Instruction Manual
Model# PH01-S, PH01-SS
Item # 60788,60368,60485,60786,61185,61444
FOR YOUR SAFETY:
If you smell gas:
1.Shut off gas to the appliance.
2.Extinguish any open flame.
3.If odor continues, keep away from the appliance and
immediately call your gas supplier or fire department.
DANGER indicates an imminently hazardous situation
which,if not avoided, will result in death or serious
injury.
Failure to comply with the precautions and instructions
provided with this heater can result in death,serious
bodily injury and property loss or damage from hazards
of fire, explosion, burn,asphyxiation, and/or carbon
monoxide poisoning. Only persons who can understand
and follow the instructions should use or service this
heater.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
An LP-cylinder not conected for use shall not be stored
in the vicinity of this or any other appliance.
Improper installation, adjustment,alteration,service or
maintenance can cause property damage,injury or
death.Read the installation, operation and maintenace
installation, operation and maintenance instructions
thoroughly before installing or srevicing this equipment.
Purchase Date _____________
1
DANGER
!
DANGER
!
DANGER
!
WARNING
!
WARNING
!
WARNING
!
FOR OUTDOOR USE ONLY!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PH01-S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fire Sense PH01-S

Summary of Contents for Fire Sense PH01-S

  • Page 1 Outdoor Patio Heater Instruction Manual Model# PH01-S, PH01-SS Item # 60788,60368,60485,60786,61185,61444 DANGER FOR YOUR SAFETY: If you smell gas: 1.Shut off gas to the appliance. 2.Extinguish any open flame. 3.If odor continues, keep away from the appliance and immediately call your gas supplier or fire department.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Table of Contents………………………………….....Page 2 Before You Begin............Page 2 Safety Information............Page 3-4 Package Contents………………………………….....Page 5 Hardware Contents............Page 6 Assembly.................Page 6-11 Operating Instructions……………........Page 12-15 Care and Maintenance……………………......Page 15 Troubleshooting……………………………………......Page 16 Replacement Parts List.............Page 17 Warranty Information……………........…Page 18 BEFORE YOU BEGIN Please read and understand this entire manual before attempting to assemble, operate or install this appliance.

  • Page 3: Safety Information

    SAFETY INFORMATION DANGER DANGER * EXPLOSION - FIRE HAZARD * CARBON MONOXIDE HAZARD * Keep solid combustibles,such as building materials, * This heater is a combustion appliance. All combustion paper,or cardboard a safe distance away from the heater appliances produce carbon monoxide (CO) during the as recommended by the instructions.

  • Page 4: Safety Information

    SAFETY INFORMATION WARNING WARNING * This product if fueled by propane gas. Propane gas is California Proposition 65 invisible,odorless, and flammable.An odorant is normally Combustion by-products produced when using this added to help detect leaks and can be described as product contain chemicals known to the State of having a"rotten egg"...

  • Page 5: Package Contents

    PACKAGE CONTENTS PART DESCRIPTION Reflector 3 outer pcs and 1 center cap Gas Hose 1 pc (attached to head assembly) Post Assembly 2 pcs LPG Cylinder Holder Anchoring Arms/Pins 1 pc (hardware is pre-assembled Wheel Assembly to wheel assembly) *Some models come with an optional waterbox feature. See page 8 for details on waterbox assembly.

  • Page 6: Hardware Contents

    HARDWARE CONTENTS Bolt M6x10 Barrel Bolt Qty.8 Bolt Bolt Bolt Bolt 90mm(L) M6x30 M8x16 M6x12 M8x25 Qty.3 Qty.6 Qty.3 Qty.12 Qty.3 Wing Nut Washer Washer Lock Washer Qty.3 Qty.6 Qty.18 Qty.18 Qty.4 ASSEMBLY PREPARATION Before beginning assembly of this appliance, make sure all parts are present. Compare all parts with package contents list as listed on page 5 of this manual.

  • Page 7: Assembly

    ASSEMBLY 1. Locate Wheel Assembly (12) and 2 nuts/bolts contained in plastic bag with Wheel Assembly. Turn Base (9) so that holes for attachment of Wheel Assembly are facing you. Align holes in Wheel Assembly with holes on Base. Insert bolts through both sets of holes and secure nuts on end of bolt.
  • Page 8 ASSEMBLY 2. Attach one Anchoring Arm (11) to Base (9) with 2 - M6x12 Bolts (D), M6 Washers (I) and M6 Nuts (J) as shown below (repeat with the other 2 anchoring arms so all 3 are attached to Base). NOTE: Only 2 Anchoring Arms can be used in conjunction with the Wheel Assembly.
  • Page 9 ASSEMBLY Place the Post Support (7) on top of the 3 assembled Support Legs and align the holes in the Post Support with the holes in the Support Legs. Insert 2 - M6x30mm Bolts (B) through the two holes in Support Post and through M6 Washer (I) then through hole in Support Leg and affix a 6mm Nut (J) to the bolt.
  • Page 10 ASSEMBLY 6. Screw the 3 Barrel Bolts (A) into the holes located on the top of the Head Assembly (2). Hold the Head Assembly over the assembled Post and route the Gas Hose (3) down into the Post. Rest the Head Assembly on the top of the Post and align 4 small holes on Head Assembly with 4 Small holes in Upper Post.
  • Page 11 ASSEMBLY 8. While supporting heater, tilt the Head Assembly and slide 1 pcs - M8 Washer (H) over each of the 3 Barrel Bolts, then slide the assembled Reflector over the 3 Barrel Bolts that extend from the Head Assembly. Use the 3 pcs - Wing Nuts (G) and 3 pcs - M8 Washers (H) to secure the assembled Reflector to the Head Assembly of the heater.

  • Page 12: Operating Instructions

    OPERATING INSTRUCTIONS A minimum supply pressure of .5 psi is required for the purpose of input adjustment of propane gas. Storage of an appliance indoors is permissible only if the cylinder is disconnected and removed from the appliance. A cylinder must be stored outdoors in a well-ventilated area out of the reach of children. A disconnected cylinder must have dust caps tightly installed and must not be stored in a building, garage, or any other enclosed area.
  • Page 13 OPERATING INSTRUCTIONS 3. If leak is detected at regulator/cylinder valve connection, disconnect, reconnect, and perform another leak check. If you continue to see bubbles after several attempts, cylinder valve is defective. Call our customer service hotline at 1-866-985-7877, 9 a.m. – 6 p.m., EST, Monday – Friday IF NO BUBBLES APPEAR AT ANY CONNECTION, THE CONNECTIONS ARE SECURE.
  • Page 14 OPERATING INSTRUCTIONS WARNING FOR YOUR SAFETY Be careful when attempting to manually ignite this heater.Holding in the control knob for more than 10 seconds before igniting the gas will cause a ball of flame upon ignition. When Heater is ON: Emitter screen will become bright red due to intense heat.

  • Page 15: Care And Maintenance

    OPERATING INSTRUCTIONS After Operation: 1. Gas Control Knob is in OFF position. 2. Gas tank valve is OFF. 3. Disconnect gas line. CARE AND MAINTENANCE WARNING FOR YOUR SAFETY * Do NOT touch or move heater for at least 45 minutes after use.

  • Page 16: Troubleshooting

    TROUBLESHOOTING If you have any questions regarding this product, please call our customer service hotline at 1-866-985-7877, 9a.m. – 6 p.m. (EST), Monday – Friday, or email us at cservice@welltraveled.net. PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Gas valve may be off Turn gas valve ON Fuel tank may be empty Refill LPG tank...

  • Page 17: Replacement Parts List

    REPLACEMENT PARTS LIST For questions regarding this product or to purchase replacement parts, please call our customer service hotline at 1-866-985-7877, 9a.m. – 6 p.m. (EST), Monday – Friday, or email us at cservice@welltraveled.net. PART DESCRIPTION Reflector 3 outer pcs and 1 center cap Gas Hose 1 pc (attached to head assembly) Post Assembly...

  • Page 18: Warranty Information

    Customer Service Hours: Mon. – Fri. 9:00 a.m. – 6:00 p.m. (EST) Fire Sense®, Mojave Sun ®, and Well Traveled Living® are registered trademarks of Well Traveled Imports, Inc®. All assembly instruction presentations are the property of Well Traveled Imports, Inc.® and are protected by U.S. copyrights...
