4.3 SCPI Subsystem Commands

Subsystem commands control all Z
+
7.12 in Z series User Manual. Short list of Z
OUTPut
[:STATe] <bool>
[:STATe]?
:PON
[:STATe] <bool>
[:STATe]?
:PROTection
:CLEar
:FOLDback
:DELay <NR3>
:DELay?
:ILC
:MODE <CRD>
:MODE?
:TTLTrg
:MODE <CRD>
:MODE?
:RELay
[:STATe] <bool>
[:STATe]?
:MODE?
INSTrument
:COUPle <CRD>
:NSELect <NR1>
:NSELect?
VOLTage
[:LEVel]
[:IMMediate]
:TRIGger <NR3>
:TRIGger?
+
functions. For a full command description refer to section
[:MODE] <CRD>
[:MODE]?
[:AMPLitude] <NR3>
[:AMPLitude]?
+
series commands:
Enable/Disable output
Enable/Disable output query
Set power-on state in Safe or Auto start
Power-on state in Safe or Auto start query
Reset latched protection
Protection at transition CC<->CV modes
Protection at transition CC<->CV modes query
Delay before protection activated
Delay before protection activated query
Set remote inhibit input (ENAble|DISable)
Set remote inhibit input query
Set or disable Function Strobe Mode
Function Strobe Mode query
Set programming pin status
Programming pin status query
Replay operation mode CV/CC/OFF
+
Z
Couple for all power supplies
Select the Power Supply to remote operation
Selected Power Supply
Set output voltage
Set output voltage query
Set current value for trigger pending
Set current value for trigger pending query
8
