QUICK START

1. POWER
To power the unit, connect the included DC adapter power supply to
the 9V jack (A) on the back panel.
Note: Using a non-Source Audio supply could damage the unit.
Please be very cautious when using 3rd-party power supplies.
2. GUITAR/AUDIO CONNECTIONS
Using standard ¼" mono cables, plug your guitar, bass, or other
instrument into the GUITAR IN (B) jack and from the GUITAR OUT (C)
jack to your amp or other audio device.
MULTI-
FUNCTION
3. BRIEF KNOB, FOOTSWITCH, AND BUTTON DESCRIPTIONS
(see Controls section for more details)
• EFFECT KNOB (A):
• DEPTH (B):
4 | Quick Start
GUITAR IN
IN
B
Selects the filter type.
Controls the depth of the filter sweep.
GUITAR OUT
MULTI-
FUNCTION
OUT
C
9V DC
A
