OPTION (C):
•
• SPEED (D): Adjusts the attack and decay rate of the envelopes, the rate of
the LFO (Low Frequency Oscillator), or the "Smoothing" of the Hot Hand.
• MOD SOURCE (E): Selects between the envelopes, sine wave LFO, square
wave LFO, and sawtooth wave LFO.
• OPTION SELECT (F): Selects which parameter will be controlled by the
OPTION knob.
• CONTROL INPUT (G): Selects which external controller type will be used.
• FOOTSWITCHES (H): Enables/Disables presets. Press and hold either
footswitch to save an edited preset.
A
DEPTH
B
F
OPTION
SELECT
(HOLD)
DEFAULT
C
H
Adjusts the parameter selected by the OPTION SELECT button.
SHADOW
THRU
ZERO
FLANGER
CLASSIC
CHORUS
QUAD
DELAY/FREQ
FEEDBACK
DUAL
VOLUME
TREMOLO
MIX
1
OPTION
RESONATOR
RES 1
O RB I TAL
RES 2
MODU
VIBE
PHASER
4 STAGE
6 STAGE
8 STAGE
12 STAGE
ENV+ ENV-
MOD SOURCE
L A T OR
SPEED
HH
MIDI
EXP
CONTROL
INPUT
2
Quick Start | 5
D
G
E
H
