Figure 2: 850 Pattern Generator Rear Panel - Kramer MultiTOOLS 850 User Manual

# Feature
4
5
6 2-digit 7-segment Display
7 ON LED
– Button
8
9 + Button
Figure 2

Figure 2: 850 Pattern Generator Rear Panel

# Feature
10 DP OUT Connector
11 RS-232 9-pin D-sub
Connector
12 USB Connector
13 5V DC Connector
850 - Overview
850 Front Panel Features
Function
CS/ASF Press to select either the Color Space (when the ON/OFF button is
on) or Audio Sample Frequency functions (when the ON/OFF
button is off)
DELAY/ASD Press to select either the Delay (when the ON/OFF button is on) or
Audio Sample Data functions (when the ON/OFF button is off)
Indicates the current setting. The display flashes if there is a
problem communicating with the display, for example, if the display
does not support HDCP or does not support the selected resolution
Lights red when the device receives power
Press to step down through the list of available values
Press to step up through the list of available values
defines the rear panel of the 850.
850 Rear Panel Features
Function
Connect to the DisplayPort acceptor (see
Connect to the serial port on a PC for remote control (see
Section
Connect to a USB port on a PC for remote control
Connect to the power adapter
4.1.1)
Section 4)
5
