Figure 13: User Defined Resolution Advanced Window–Additional Tab
5. Select the required aspect ratio and resolution.
6. Click OK to save the additional parameters or click the Advanced button to
edit the timing parameters and EDID values.
The Advanced Window appears with the Timing Parameters tab selected
as shown in
18
Figure 14.
850 - Operating the 850 Pattern Generator
