Summary of Contents for Kramer 840H
-
Page 1: User Manual
Kramer Electronics, Ltd. Preliminary USER MANUAL Model: 840H HDMI Pattern Generator... -
Page 2: Table Of Contents
Figure 1: 840H HDMI Pattern Generator Figure 2: Connecting the 840H HDMI Pattern Generator Tables Table 1: 840H HDMI Pattern Generator Features Table 2: Selecting the HDMI Output Resolutions Table 3: Pattern Number Definitions Table 4: Technical Specifications of the 840H HDMI Pattern Generator... -
Page 3: Introduction
HDMI cables, as well as testing the refresh rates of LCD displays by using the motion patterns. Note, that the Kramer 840H is identical to the 840HDMI; just the name has changed replacing the suffix “HDMI” by “H” (according to the HDMI Guideline). -
Page 4: Overview
Overview Overview The 840H is a high performance HDMI Video test pattern generator. It displays 32 preset patterns at 11 popular computer and HD video resolutions including several unique patterns incorporating motion. The HDMI output signal includes: SVGA (800x600), XGA (1024x768), SXGA (1280x1024), 1400x1050, 852x480, 1280x720, 1366x768, 1440x900, 720x480, 1920x1080, and 1920x540. -
Page 5: Quick Start
Overview Quick Start This quick start chart summarizes the basic setup and operation steps. -
Page 6: Your 840H Hdmi Pattern Generator
Your 840H HDMI Pattern Generator Your 840H HDMI Pattern Generator Figure 1 Table 1 define the 840H HDMI Pattern Generator (Table 2 summarizes how to select each HDMI Output Resolution): Figure 1: 840H HDMI Pattern Generator KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 7: Table 1: 840H Hdmi Pattern Generator Features
Your 840H HDMI Pattern Generator Table 1: 840H HDMI Pattern Generator Features Feature Function 12V DC +12V DC connector for powering the unit OUTPUT Connector Connect to the HDMI acceptor ON LED Illuminates when receiving power PATTERN NUMBER Shows the pattern number (from 00 to 31) -
Page 8: Using Your 840H Hdmi Pattern Generator
Figure 2: Connecting the 840H HDMI Pattern Generator 1 Switch OFF the power on the HDMI acceptor before connecting it to your 840H. After connecting your 840H, switch on its power and then switch on the power on the HDMI acceptor... -
Page 9: Operating Your 840H Hdmi Pattern Generator
Table 3) are programmed into the 840H HDMI Pattern Generator, in order to assess various aspects in the flat panel LCD display, projector, Plasma screen or cable. For example, the 840H tests a: • Flat panel LCD display by testing if all the pixels illuminate with... -
Page 10: Interpreting Each Pattern Number Definition
Using Your 840H HDMI Pattern Generator Interpreting Each Pattern Number Definition Table 3 describes each of the 32 different Patterns: Table 3: Pattern Number Definitions PATTERN NUMBER DEFINITION Black screen 75% saturated color bar 100% saturated color bar Grayscale bar... -
Page 11: Technical Specifications
Technical Specifications Technical Specifications Table 4 includes the technical specifications: Table 4: Technical Specifications of the 840H HDMI Pattern Generator OUTPUT: 1 HDMI connector HDMI OUTPUT SVGA (800x600), XGA (1024x768), SXGA (1280x1024), 1400x1050, 852x480, RESOLUTIONS: 1280x720, 1366x768, 1440x900, 720x480, 1920x1080, and 1920x540. All... - Page 12 EXCLUSION OF DAMAGES The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall not be liable for: 1. Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;...
- Page 13 For the latest information on our products and a list of Kramer distributors, visit our Web site: www.kramerelectronics.com, where updates to this user manual may be found. We welcome your questions, comments and feedback. Safety Warning: Disconnect the unit from the power supply before opening/servicing.
