Operating the 850 Pattern Generator

The 850 can be operated using the front panel buttons (see
850 Control Application (see
The 850 Control Application is available as a free download from
http://www.kramerelectronics.com).
The following output video resolutions are supported.
# Resolution
1 VGA 640 x 480 @60Hz
2 SVGA 800 x 600 @60Hz
3 XGA 1024 x 768 @60Hz
4 1280 x 720 @60Hz
5 1280 x 1024 @60
6 WSXGA+ 1680 x 1050 @60Hz
7 SXGA 1280 x 1024 @75Hz
8 HD 1920 x 1080 @60Hz
9 WUXGA 1920 x 1200 @60Hz
10 UXGA 1600 x 1200 @60Hz
11 2048 x 1280 @60
12 2048 x 1152 @60
The following video patterns are supported.
# Pattern
1 100% Color bar
2 75% Color bar
3 Gray bar
4 Red screen
5 Green screen
6 Blue screen
7 Yellow screen
8 Cyan screen
9 Magenta screen
10 Gray screen
11 White screen
12 RGB ramp
13 Black screen
14 Crosshatch black
15 Crosshatch green
16 Crosshatch blue
850 - Operating the 850 Pattern Generator
Section 5.2).
Resolution Values
# Resolution
13 2048 x 1536 @60
14 1856 x 1392 @60
15 2560 x 1440 @60
16 2560 x 1600 @60
17
18
19
20 User defined
21
22
23
24 Output native resolution
Pattern Values
# Pattern
17 Square
18 White dot
19 Alternate pixels
20 White HScroll
21 White VScroll
22 Multiburst
23 Vertical split
24 Horizontal split
25 Red ramp
26 Green ramp
27 Blue ramp
28 Bounce
29 Window
30 White border
31 Target circle
32 Moving ball
Section 5.1) and the
11
