CS14, CSN14 Series Converter Switches
TR+PS9X2 Model has two groups of eight units per power supply. The power supplies
area of the tray. (PS units that come with the MC's are not used).
www GarrettCom com
.
.
Installation and User Guide (02/06)
have auto-ranging AC input for use
worldwide.
The side-view below is an example
of an installation of the model
MC14-TR+PS9, 19" rack-mount
tray, holding a few CS14 and
CSN14, FT14 and 14E Media
Converters, each with their power
input plugged into the built-in
common AC power supply in the rear
42
