9 ON SCREEN MENUS

SOURCE SELECTION
The Source Selection menu is recalled by pressing the key:
0/AV of the remote control or the Up/Down Arrow key of the
keyboard pad. The selected source will be highlighted in yellow.
Use Up and Down Arrow keys to browse sources. Right
Arrow to select the desired source.
Alternatively, use the remote control to directly select the
required source (1 to 8).
Source Selection
1 Video
2 S-Video
3 RGBS 15 kHz
4 YCrCb 15 kHz
5 RGBS 32 kHz
6 YCrCb 32 kHz
7 Graphics RGB
When a new source is selected a box appears on the screen
with the following indications: selected source, standard vi-
deo (for video signals), resolution (for graphic signals) and
aspect (Fig. 24).
Video
NTSC/60Hz
Normale
MAIN MENU
To access the main On Screen Display menu, press the Menu
key on the keyboard or the key Menu + or Menu - on the
remote control (Fig. 25) .
14
The main menu is divided into four sections to cover various
adjustments in a practical and logical manner.
The on-screen menu layout is dependant upon the chosen input
signal so various options may not be applicable, i.e. some typical
adjustments to the video signal are not applicable to the graphic
RGB signals from PC and viceversa.
This menu features adjustments relating to the projected image
quality.
Fig. 24
BRIGHTNESS 20
CONTRAST 50
COLOR 50
SHARPNESS 7
FILTER 6
CINEMA MODE Off Auto
VIDEO TYPE Normal VCR1 VCR2
BRIGHTNESS 20
CONTRAST 50
50
COLOR
85
TINT
SHARPNESS 7
FILTER 6
CINEMA MODE Off Auto
VIDEO TYPE Normal VCR1 VCR2
VIDEO
VIDEO-NTSC
