DOMINO 55M
RS-232C
CONTROL

SPECIFICATIONS

Document Revision 1.0 (18 February 2005)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DOMINO 55M and is the answer not in the manual?

Questions and answers

Related Manuals for Sim2 DOMINO 55M

Summary of Contents for Sim2 DOMINO 55M

  • Page 1: Specifications

    DOMINO 55M RS-232C CONTROL SPECIFICATIONS Document Revision 1.0 (18 February 2005)

  • Page 2: Table Of Contents

    3. COMMUNICATION PROTOCOL EADER AYLOAD 4. COMMANDS EMOTE ONTROL ODES PERATION ODES ODES 5. EXAMPLES 6. WARNINGS Revision History: Revision Date 21 January 2004 Software Version 2.44.00 M or higher SIM2 DOMINO 55M RS-232C CONTROL SPECIFICATIONS Description of Change Initial version.

  • Page 3: Introduction

    Switch off your Personal Computer and DOMINO 55M before connecting RS 232C cable. Use a standard serial cable with 9 pin female to the Personal Computer and 9 pin male to the DOMINO 55M: pin 2 connects to pin2, pin 3 to pin 3 and pin 5 to pin 5.

  • Page 4: Communication Protocol

    The Event packet payload size is 6 bytes, while the Operation packet payload size is 25 bytes. Event Packet Format: Event Operation Packet Format: Op Type Op ID Packet Type Packet Payload Size Op Target SIM2 DOMINO 55M RS-232C CONTROL SPECIFICATIONS Packet Checksum (CRC) Op Value...

  • Page 5: Commands

    4. Commands Remote Control Key Codes The following commands send simulated Remote Control input to SIM2 DOMINO 55M. Remote Control Keycodes: STAND BY CURSOR UP CURSOR LEFT CURSOR RIGHT CURSOR DOWN MENU LEFT MENU RIGHT FREEZE MEMORY INFO AUTO ASPECT NORMAL...

  • Page 6: Direct Access Codes

    BE EF 02 06 00 16 E0 7F 01 00 00 00 00 BE EF 02 06 00 19 F4 80 01 00 00 00 00 BE EF 02 06 00 C8 F5 81 01 00 00 00 00 SIM2 DOMINO 55M RS-232C CONTROL SPECIFICATIONS...

  • Page 7: Operation Codes

    Operation Codes The following codes provide direct access to SIM2 DOMINO 55M User Interface operations not accessible via a single Remote Control command. Operation Codes: Operation Action INCREMENT BRIGHTNESS DECREMENT INCREMENT CONTRAST DECREMENT INCREMENT COLOR DECREMENT INCREMENT TINT DECREMENT INCREMENT...
  • Page 8 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 BE EF 03 19 00 13 C6 04 62 08 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 SIM2 DOMINO 55M RS-232C CONTROL SPECIFICATIONS...
  • Page 9 BE EF 03 19 00 A7 E3 01 28 09 00 00 03 00 00 00 01 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 Packet Type Packet Payload Size SIM2 DOMINO 55M RS-232C CONTROL SPECIFICATIONS Packet Checksum (CRC)

  • Page 10: Get Codes

    Op ID Get Codes Get Commands may be used to get the current value of DOMINO 55M parameters. The response to a correct Get Command consists of 33 byte packet, where Byte Number 11 contains the Validation Code (01) and bytes Number 17 and Number 18 the requested value (the least-significant byte of the value being sent first).

  • Page 11: Examples

    BEEF02060080E5490100000000. The DOMINO 55M switches on and selects Input 1. The DOMINO 55M returns the response code: 06 (Acknowledged with no error). NOTE: Commands that simulate keys "1", "2" ... "7" switch on the unit and select the corresponding Source.

  • Page 12: Warnings

    BEEF02060062E44B0100000000 6. Warnings When the number of bytes sent to the DOMINO 55M is greater than indicated for the Command (32 bytes for Operation Packets and 13 bytes for Event Packets), excess data will be ignored. Conversely, if number of bytes sent to the DOMINO 55M is smaller than required by the Communication Protocol, the command may be ignored.
