RAID

The C3 Series integrated RAID solution provides cost benefits for customers who desire
extra performance or storage capacity. The two components of integrated RAID are:
•
Integrated Striping (IS), which provides features of RAID 0
•
Integrated Mirroring (IM), which provides features of RAID 1
Setting Up the RAID Configuration
IMPORTANT!! All data will be erased when creating RAID 0 or RAID 1. The user must
back up files when necessary. Elo Touch Solutions does not accept liability for lost data or
software. Please burn copies of your recovery DVD(s) before performing this process. The
ISO files (images) for these DVD(s) are located on the system desktop in the [Recovery
DVD ISO Files] folder. Please see the "Recovering The Operating System" section of this
user's guide for more information.
1. Power off your system completely.
2. Power on your system.
3. After the Elo splash screen (shown below), press DEL repeatedly to enter BIOS
Setup.
4. Go to Advanced -> SATA Configuration.
5. On RAID Mode Selection, select your preferred RAID configuration (Note: If you
would like to change RAID mode from RAID 0 to 1 or RAID 1 to 0, you have to set your
RAID mode to "Clear" , save your settings, and complete a "power on/off" cycle. Then
go back into the BIOS following this procedure completely beginning with step 1 to set
the desired RAID mode..)
