Parameter
TFTP Server IP address
Configuration File name
Firmware file name
Kernel File name
Software Version
Hardware Version
5.5

VoIP Dialing settings

The VoIP Dialing Parameters screen displays the dialing and door opening definitions.
The VoIP Dialing screen contains the following areas:
Parameter Name and Parameters area:
Parameter
DTMF SIP Presentation mode
Speed Access Codes 1 to 10
Pancode VoIP/Pantel VoIP Access Control Door Phones
Description
An identifier for the TFTP server on a TCP/IP network, where configuration
files will be stored. The TFTP server can be activated by using the Third Part
Company tftp software. For example: Tftpd32 application, which can be
found on the following URL:
http://www.snapfiles.com/download/dlTftpd32.html )
Previously saved configuration file name, which has to be written here and
IP Door Panel will upload it using tftp server settings.
Internal IP Door Panel Firmware file name. Uploading procedure is the
same as Configuration file.
Internal IP Door Panel Kernel file name. Uploading procedure is the same
as Configuration file. This parameter may be changed by a qualified
and authorized person only!
Displays the IP Door panel internal software number.
Displays the IP Door panel internal hardware edition number.
Pancode VoIP has two dialing modes: standard and sped-dial. Pantel
VoIP has the standard mode only.
Description
Defines the mode of providing DTMF tone information in the SIP VoIP
network. Possible choice: RFC 2833 or Transparent (In-Band DTMF).
Access Door Opening Codes (speed-dial mode) fields – contain door-
opening codes in speed-dial mode. Each field can contain a code of up to
8 digits, which opens the door lock. Legal entries: 0-9 digits only. All codes
in this mode must start with 0.
Installation and Programming Manual
38
