Parameter
IP Camera Type *
IP Camera Enabling DHCP *
IP Camera IP Address *
IP Camera Subnet mask*
IP Camera Gateway *
IP Camera stream Type *
Software Version
Hardware Version
7.4

VoIP Dialing settings

The VoIP Dialing Parameters screen displays the dialing and door opening definitions.
The VoIP Dialing screen contains the following areas:
Parameter Name and Parameters area:
Parameter
DTMF Transfer type
Speed Access Codes 1 to 10
Pancode VoIP/Pantel VoIP Access Control Door Phones
Description
Type of the digital video camera used in the IP Door panel.
Enables the DHCP mode for the digital video camera.
Identifies the Pantel VoIP/Pancode VoIP digital video camera on the TCP/IP
network. Legal entry: digits 0-9 only. Example: 192.168.21.10.
A mask that determines to which subnet an IP address belongs. Legal
entry: digits 0-9 only. Example: 255.255.255.0.
An identifier for the default gateway on a TCP/IP network.
The video stream type supported by the digital video camera.
* Feature activity depends on the IP Door Panel hardware and software
configuration. Contact the local dealer or manufacturer for details.
Displays the IP Door panel internal software number.
Displays the IP Door panel internal hardware edition number.
Pancode VoIP has two dialing modes: standard and sped-dial. Pantel
VoIP has the standard mode only.
Description
Defines the mode of providing DTMF tone information in the SIP VoIP
network. Possible choice: RFC 2833 or Transparent (In-Band DTMF).
Access Door Opening Codes (speed-dial mode) fields – contain door-
opening codes in speed-dial mode. Each field can contain a code of up to
8 digits, which opens the door lock. Legal entries: 0-9 digits only. All codes
in this mode must start with 0.
