Pancode VoIP/Pantel VoIP Access Control Door Phones
1. After power-up or reset, the Pancode/Pantel device starts an
initialization process, which can take up to 20 seconds. The
initialization completion is indicated by short busy signal.
2. Device can be detected in the LAN by using the MAC address
shown on the label and QUERY utility from the installation CD.
In cases where the MAC address is unknown, device can be
detected by using the SCAN utility from the installation CD (see
Paragraph 7.1 and 7.2).
3. When SIP parameters are updated, an automatic power reset is
required. The programming is not done in real time. Make sure
to apply the settings to the unit.
Figure 4-3. Unit Connectors
Figure 4-4. RJ-45 Connector
Installation and Programming Manual
M
1 8
F
12
