VoIP Dialing Settings
The Main Parameters screen contains the following operational buttons:
Submit
Reset to default
Reboot
Upload Config File
Save Config File
Upload Firmware
Upload Kernel
5.4

System Parameters

The following table details the system parameters. You may require assistance from your LAN administrator.
Parameter Name and Parameters area:
Parameter
User Name
Account Password (password)
IP Address – Local Address
Subnet Mask
Default Gateway
Pancode VoIP/Pantel VoIP Access Control Door Phones
Speed dialing mode Door Access Codes
Speed dialing mode destination numbers
Regular (Normal) Direct dialing mode First digits of Extensions
Regular (Normal) dialing mode Door Access Codes
Call Button definitions
Door opening from extension code
No answer timeout
Upload modified settings to the Door Unit
Reset Door Unit to the factory default settings
Restarts the Door Unit
Upload previously saved Door Units configuration file. ( Note: Saved file
renamed to Config.CFG)
Save existing Door Panel configuration as file on local PC drive (the
existing configuration file will be saved with extension Config.SAV. For
uploading this file need to rename saved file to extension Config.CFG)
Activate the updating of the Door Unit's internal firmware. This operation
requires original firmware file provided by manufacturer or local dealer.
Description
Contains the unit identification as an SIP proxy server account or VoIP
peer-to-peer network. Legal entry: 5 to 20 characters 0-9, A-Z, a-z.
Contains the unit authorization on the SIP proxy server. Legal entry: 5 to
20 characters 0-9, A-Z, a-z.
Identifies the Pantel VoIP/Pancode VoIP device on the TCP/IP network.
Legal entry: digits 0-9 only. Example: 192.168.21.10.
A mask that determines to which subnet an IP address belongs. Legal
entry: digits 0-9 only. Example: 255.255.255.0.
An identifier for the default gateway on a TCP/IP network for cases, when
the Proxy server presents out of local LAN network. Legal entry: 0-9 digits
only. Example: 192.14.21.210.
