7.

Technical Specification

Power supply
Power Consumption
Communication interface
DC Leakage
Imbalance ratio
Return loss
Relay switching current
VoIP protocol supported
Supported codecs
Echo canceller
Quality Enhancement
Echo canceller length
IP media features
In-Band Signaling Detection and
Generation
Dimensions
Dimensions Flush Mounted Unit
Weight
Operating temperature
Pancode VoIP/Pantel VoIP Access Control Door Phones
12V AC; 1.5A or Power Over Ethernet IEEE 802.3af compliant
12 V DC 3A – for devices with the video over IP option ( Analog camera
and internal video web-server)
1. Without analog video camera and AV server card: 3.6W
2. With analog video camera and AV server card: 7.2W
Note: The Maximum power consumption (short) pick value may be up to
30% higher then listed below.
Ethernet for voice; and for programming
<10 µA
300-3400Hz > 46dB
300-3400Hz > 18dB
2A max
SIP; RTP; RTCP
G.711 PCM (µ/A-Law) at 64 kbps
G.168-2002 Compliant with programmable echo tail of up to 128 msec.
Full duplex, acoustic EC
Comfort Noise generation (CHG)
Packet Loss Concealment (PLC)
Adaptive Jitter Buffer(up to 300 msec)
Up to 64 msec
Automatic Gain Control
DTMF TIA464B
19.4 X1 0.2 cm
Flush Panel:13.8 x 23.3cm / 5.4 x 0.9 inch
Flush Mounted part:9.8 x 19 x 2.5 cm/3.8 x 7.5 x 0.9 inch
0.9 kg
0ºC to +55ºC / 32ºF to 131ºF
0ºC to +35ºC / 32ºF to 95 ºF with analog video camera
0ºC to +30ºC / 32ºF to 86 ºF, including analog video camera and A/V IP
video server card
