Installing the Pantel VoIP/Pancode VoIP

The Pantel VoIP/Pancode VoIP can be installed as an individual access control or used with adjacent access-
control devices, such as card reading devices (see Section 4.2).
The provided 12V AC or 12V DC external power supply should not be located further than 10m (30ft) from the
unit.
These units also support Power Over Ethernet (PoE), meaning that they could operate when connected to
Ethernet without mains. However, the current provided by the PoE supply is insufficient for opening a
door. If your system is equipped with door lock relay, make sure to use the external supply.
Figure 4-1 shows the terminal locations on the wire connector provided with the unit. This connector is attached
at the base of the internal component. All wiring to the unit is attached to the wire connector.
The Pantel VoIP/Pancode VoIP supports a bypass switch installation. This allows opening the door with a
hardwired switch. A bypass switch should be connected to the SW and /SW terminals.
Pancode VoIP/Pantel VoIP Access Control Door Phones
When holding the unit as displayed in Figure 4-3, the first pin from
the right is the first ~12V pin.
Device accomplished with the IP (Video over IP)
internal video camera and video server supplied
with the 12 V DC external power supply. Check
the power supply connections polarity. Incorrect
connectivity can destroy device.
Installation and Programming Manual
9
