Parameter
Call Button Destination
Forward no Answer
Door opening code from
extension
Access Codes 1 – 10
Peer IP Address
Peer Mode
No answer Time Out
Off Hook Time Out
Inter Digit Time
Pancode VoIP/Pantel VoIP Access Control Door Phones
Description
Contains the number of the target phone, which will be dialed if a
destination number dialed by visitor is not answer during specific time
interval. You may insert up to 20 entries.
Legal entries: digits 0-9, ABCD, *, #.
See also " No Answer Time Out" parameter
Legal entry: from 1 to 15 digits 0-9
Enables to set a code of up to four digits, which could be dialed from any
extension during conversation to open the door.
Legal entry – up to 4 digits (0-9) code
Access Door Opening Codes fields – contain door opening codes. Each
field can contain a code of up to 8 digits, which opens the door lock.
Legal entries: 0-9 digits only. An access door-opening code cannot
begin with digits that are used as direct call prefix number.
Specify the target Peer device's IP address when Peer mode is activated.
Used mostly for functionality testing purposes. Specify the following type
of operation: Visitor dials any free up to 3 digits number and IP Door panel
try to establish SIP connection with the target Peer device, where dialed
digits used as fourth quarter of the IP address. For example:
Peer IP Address is 192.168.21.XXX, where last XXX digits are
insignificant.
Visitor dialed 151.
Door panel started to establish connection with the IP address
192.168.21.151
Time interval, when a call will be forwarded to the another destination
specified in the Call Button Destination Forward no Answer
parameter when destination dialed by visitor did not answer.
Legal entry: 0 – 9999 seconds
This parameter is relevant if the Auto Answer mode is disabled. Specify a
maximum time interval in seconds, when the IP Door Panel can be in the
No Answer mode during incoming call before rejecting the call. During
this time device indicates about incoming call by short beeps
Legal entry: 0 – 99 seconds
The maximum allowed keypad dialing inter digit time out interval. Expired
time interval time shows to door unit that the destination number or entry
code dialing process is finished. Parameter can be set in msec, default
value is 3000 msec = 3 seconds
