Instructions Owner: Director of Consulting
Instructions Name: CK70 Configuration
1. Purpose
The purpose of this instructional document is to act as a general training guide for the
configuration of the Intermec CK70 device for use with Radley software.
2. Definitions & Acronyms
WEP – Wired Equivalent Privacy
PSK – PreShared Key
RPCC – Radley Portable Client Communications
IP Address - Internet Protocol Address – defined by Network Administrator
SSID – 'Network Name' or identifier – defined by Network Administrator
Subnet Mask – Secondary IP parameter – defined by Network Administrator
3. Referenced Documents
N/A
4. Instructions
1. Battery
A. Charging the Battery
2. Network
A. Configure Network Settings
Grsp/Radley Grand Rapids Documents/Technical Documents/Customer Training Documents/Hardware
Auditor:____________________________ Audit Date: ______/______/______
CK70 Configuration
i. Completely charge battery prior to device use/configuration.
i. Access Menu System
1. Turn on device
2. Open Start menu
3. Select Setting icon
4. Select System icon
5. Select Intermec Settings
a.
Creation Date:8/18/11
Main Menu view:
Page 1 of 9
Revision Date: 7/1/13
Page: 1 of 9
Creation Date: 8/18/11
Revision Date: 07/01/2013

Advertisement

loading
Need help?

Need help?

Do you have a question about the CK70 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intermec CK70

Summary of Contents for Intermec CK70

  • Page 1 CK70 Configuration 1. Purpose The purpose of this instructional document is to act as a general training guide for the configuration of the Intermec CK70 device for use with Radley software. 2. Definitions & Acronyms WEP – Wired Equivalent Privacy PSK –...
  • Page 2 Instructions Owner: Director of Consulting Creation Date:8/18/11 Revision Date: 7/1/13 Page: 2 of 9 Instructions Name: CK70 Configuration ii. Network Configuration 1. Use touch pen 2. Select Communications a. ‘802.11 Radio’ b. Menu view: 3. Expand IP settings a. Enter device details:...
  • Page 3 Instructions Owner: Director of Consulting Creation Date:8/18/11 Revision Date: 7/1/13 Page: 3 of 9 Instructions Name: CK70 Configuration b. IP Address c. Subnet Mask d. Default Router e. Click ok to save 9. Click ok to return to 802.11 menu 10.

  • Page 4: Loading Files

    Double click the cab file from device B. Option 2a – ActiveSync ( Pre Windows 7 ) i. Connect CK70 dock to computer using a USB to Micro cable and make sure the dock has the AC power cord connected.
  • Page 5 C. Option 2b – Windows Device Center ( Post Windows 7 ) i. Connect CK70 dock to computer using a USB to Micro cable. ii. Install Windows Device Center on the PC if it is not already installed. Grsp/Radley Grand Rapids Documents/Technical Documents/Customer Training Documents/Hardware...
  • Page 6 Instructions Owner: Director of Consulting Creation Date:8/18/11 Revision Date: 7/1/13 Page: 6 of 9 Instructions Name: CK70 Configuration 1. If device is placed in dock, remove device and place it into dock. 2. Click “Connect without setting up your device”...
  • Page 7 Instructions Owner: Director of Consulting Creation Date:8/18/11 Revision Date: 7/1/13 Page: 7 of 9 Instructions Name: CK70 Configuration a. Navigate to the TEMP directory on the device and click the cab file and accept the defaults for installing. D. NOTE: If using “Windows Mobile Device Center”...
  • Page 8 Instructions Owner: Director of Consulting Creation Date:8/18/11 Revision Date: 7/1/13 Page: 8 of 9 Instructions Name: CK70 Configuration 3. “USB to PC” 4. UNCHECK the box save and then re-dock the device and it should work. a. Uncheck the box and hit OK, this should restore communications between PC and Docked Device.

  • Page 9: Revision History

    Creation Date:8/18/11 Revision Date: 7/1/13 Page: 9 of 9 Instructions Name: CK70 Configuration ii. After the cab file has been installed on device, and device communications have been verified then configure device in RPCC. iii. Reference: Radley Portable Client Communications Instructions 1.
